ENTRANCE DOORS NON INSULATED SYSTEM SMARTIA M15000
ENTRANCE DOORS NON INSULATED SYSTEM SMARTIA M15000
Smartia m15000 is one of the most completed non-insulated aluminium system which serves a wide range of various entrance doors with satisfying performance.
INFORMATION
BRAND
Alumil
PRODUCT TYPE
Entrance Doors
SEALING METHOD
Perimetrical at 3 levels with EPDM gaskets
VARIOUS DESIGNS
- Flat
- Curved
- Classic
CODE
M15000
COLLECTION
Smartia
FLEXIBLE GROOVE HARDWARE OPTIONS
Either European groove or PVC groove hardware can be applied
COMPATIBILITY
The system also supports "block window" constructions (concealed sash)
MAXIMUM GLAZING THICKNESS
5 up to 40 mm
EXTERIOR SHAPE
Flat
THERMAL INSULATION
No
ENVIRONMENT
Outdoor
INSULATION PANEL
Fixed
ADVANTAGES
- High functionality
- Good security level
- High value for money
- Good sound insulation
- Variety of profile design
MINIMUM THRESHOLD HEIGHT
18.5 mm
MINIMUM VISIBLE ALUMINIUM FACE HEIGHT
116.4 mm
FRAME DEPTH
50 mm
GLAZING TYPE
Single - Double
MATERIAL
Glass & Aluminium
PRODUCTION
Made in Greece
BURGLAR RESISTANCE
RC2
MECHANISM
Perimetrical Locking Mechanism
MINIMUM VISIBLE ALUMINIUM FACE WIDTH AT THE CENTRAL VERTICAL COLUMN (ADJOINING PROFILE)
61 mm
SYATEM
Robust & flexible system that can support all potential typologies of hinged doors, windows & pivot windows Available special profiles for main entrances, smoke proof doors and panic doors
SASH DEPTH
50 mm
SASH WEIGHT
Up to 180 Kg
CERTIFIED PERFORMANCE
Certified performance by the IFT Rosenheim Institute
