Serge Ferrari Stamisol Extreme Dw Facade
STAMISOL EXTREME DW FACADE
STAMISOL EXTREME DW FACADE
Facade membranes
INFORMATION
BRAND
Sergeferrari
PRODUCT TYPE
Facade Membranes
MAXIMALE EINSATZTEMPERATUREN
- 40°C/+ 80°C
ARCHITECTURAL FREEDOM WITH TECHNICAL ASSURANCE
-Unleash your creativity without compromise: Stamisol Extreme DW allows the use of highly open cladding systems while delivering premium thermal and mechanical protection -Its enhanced UV resistance—double standard requirements—ensures long-lasting durability, while its robustness makes it a reliable solution for exposed façades. Combined with certified Stamisol accessories, it ensures watertight finishing and up to 24 months of weather resistance during the construction phase.
CLASSEMENT
VKF 5.2* (RF 2)
ENDUCTION
Polyacrylate
STAMISOL EXTREME DW: ULTRA-RESISTANT AND BREATHABLE FAÇADE MEMBRANE
LAIZE
250 cm
EUROCLASSE
E
UMWELT - COMMUNICATION ENVIRONNEMENTALE
ISO 14021
POIDS DE LA COUCHE DE PROTECTION POLYACRYLATE
265 g/m²
DURABILITY, DESIGN FREEDOM, FAÇADE SAFETY
-Stamisol Extreme DW is classified Euroclass E (VKF 5.3 / RF2) and provides proven watertightness in accordance with EN 1928 (800 mm water column) and TU Berlin testing. After prolonged UV exposure, it retains its mechanical performance. Its high breathability reduces condensation risk, and its flexibility down to –30°C ensures easy installation, even in winter conditions. -It can remain exposed for up to 24 months before final cladding installation and comes with a 10-year system warranty.
POIDS TOTAL
380 g/m²
QUALITÉ
ISO 9001
RÉSISTANCE À LA RUPTURE (L/T)
- 520/470 N/5cm
- ≥ 95% vor Alterung - W1
- ≥ 95% valeur avant vieillissement W1
SD-WERT - VALEUR SD
≤ 0,06 m
WARRANTY
10-year warranty
DOWNLOAD
↓ Sample Card
RÉSISTANCE DE FLEXION À FROID
- 30°C
AVAILABLE COLOR
1
SUPPORT
Non-tissé polyester
COLORS
Black (Stamisol Extreme DW facade)
HIGH-PERFORMANCE RAINSCREEN MEMBRANE FOR HIGHLY OPEN CLADDING
Push the limits with Stamisol Extreme DW, specifically designed for open-joint façades with gaps up to 100 mm or 50% openness. Its reinforced formulation withstands extreme conditions: tested for 10,000 hours of UV exposure, it maintains W1 watertightness and mechanical strength. Suitable for all types of substructures (timber, metal, insulation), it effectively protects thermal insulation while ensuring opt
COMPLETE SYSTEM, COMPLIANCE & PERFORMANCE
Complete your façade system with:
- Stamisol Extreme DW 2TAPE, featuring integrated adhesive strips for faster installation
- Stamisol Extreme Color, for premium colored membrane solutions
- Stamisol façade accessories (adhesives, molded parts, seals) to treat critical details
ISO 9001/14001 certified, listed in WUFI, compliant with SIA 232-2, eco-bau (Minergie-Eco) labeled, and compliant with DTU 41.2 and DTU 31.2 standards.
10-year system warranty, extendable up to 20 years depending on geographic area.
