Upsideinnovations Prefabricated Commercial Metal Stairs
PREFABRICATED COMMERCIAL METAL STAIRS
PREFABRICATED COMMERCIAL METAL STAIRS
Prefabricated Commercial Metal Stairs
Our APEX Commercial Stairs are prefabricated, meaning that they are ready to install right away.
The industrial-grade aluminum components bolt together seamlessly, providing never-ending configurations.
Reduce costs and eliminate time-consuming welding with our APEX Commercial Stair System.
FEATURES
EASY INSTALLATION
Our commercial stairs are modular and bolt together.
LEVELING LEGS
Platform legs have 8” of adjustability for uneven ground or ongoing adjustments.
CODE COMPLIANT
Our commercial stairs comply with the Americans with Disabilities Act (ADA) and International Building Code (IBC) and can meet local building codes.
RECONFIGURABLE
Because the APEX System is modular, ramps, stairs and railings can be reused, added to, and reconfigured as your needs change.
MODULAR DESIGN
Modular commercial stairs, platform landings, legs, and handrails bolt together without any on-site welding.
PIVOTING RISERS
Our team of engineers will design a stair configuration layout just for you, and professional engineer stamps are available.
100% ALUMINUM – LONG LASTING
The entire line of APEX products will never rust, warp, or rot. Components are low maintenance and will last much longer than wood or steel.
SLIP-RESISTANT DECKING
APEX stairs are standard with an aggressive, heavy-duty 3” channel grip strut grating that provides maximum, multi-directional slip resistance. Other decking options are available.
HPD/LEED/ESG
Prefabricated systems are typically made with 6061 and 6063 aluminum alloys containing ≥99% and ≥50% recycled content. Some prefabricated systems can help contribute to several LEED v4.1 credits and other green building rating systems.
INFORMATION
DURABLE, LONG LIFECYCLE
100% industrial-grade aluminum that won’t rust, warp, or rot.
BRAND
Upside Innovations
PRODUCT TYPE
Stairs
DIMENSION
- Handrail : 36″ high
- Tread Depth : 2″ (11″ + 1″ nosing)
- Height : We use 6″, 6.5″, or 7″ rises between the treads to reach any height
WIDTH (STEPS > 30″)
48″ between the handrails, 60″ out-to-out
WIDTH (STEPS ≤ 30″)
48″ between the handrails, 52″ out-to-out
MATERIAL
Mill finish aluminum extrusions and sheet
REACH ANY HEIGHT
Our team can design modular stairs to reach any height that you need.
GUARDRAIL (STEPS > 30″)
42″ high
BALUSTERS
Less than 4″ apart
WE INSTALL
Our professional installation crew ensures that your project goes smoothly.
GUARDRAIL (STEPS ≤ 30″)
Guardrail incorporated below handrail
POWDER COATING (OPTIONAL)
Ask a solutions advisor for available color options
PLATFORM SIZES
64″ x 64″, 64″ x 96″, 72″ x 72″ (other sizes available)
WEIGHT CAPACITY
100 lbs/sqft live load, 300 lbs point load over a sqft area
DESIGN
As the manufacturer, we can design commercial stairs to your specifications… however unique. Because units are prefabricated and bolt together, stairs come ready to install without the need for special tools or equipment.
PRODUCT RESOURCES
- BIM/CAD Files
- Specifications (CSI Spec)
- Elevation/Plan Views
- Environmental/LEED/HPD
- Product Info & Tech Specs
DECKING OPTIONS
- Extruded - Bar Grating
INFINITE CONFIGURATIONS
Our modular design and experienced engineers can configure solutions for the most difficult projects.
FAST INSTALLATION
Prefabricated and bolts together on-site with no welding required.
USE
Commercial Stairs
ADA & IBC COMPLIANT
Designed to your needs. ADA, IBC, and local building codes. OSHA-compliant options also available.
