TENSEO EDITION 700, 900 & 1100 – TXS SERIES CANOPIE
TENSEO EDITION 700, 900 & 1100 – TXS SERIES CANOPIE
Edition TXS 700F, Edition TXS 900F, Edition TXS 1100F
The Tenseo TXS range is designed for outdoor shade structures such as parking areas, awnings, and canopies.
It provides effective solar protection while ensuring light weight, reliability, and durability. An ideal solution for functional projects with controlled costs.
INFORMATION
MAIN ADVANTAGES
- Operational performance
- UV protection
- Lightweight
BRAND
Sergeferrari
PRODUCT TYPE
Canopie
MAIN APPLICATIONS
- Car parks
- Shading structures
- Canopies
COATING
PVC both sides lacquered
SURFACE TREATMENT (TOP)
PVDF
COMPATIBLE WITH TENSEO STRUCTURES – INTERNATIONAL CERTIFICATIONS
TXS F membranes are compatible with many Tenseo outdoor shade structures. They meet Serge Ferrari quality standards (ISO 9001, ISO 14001) and are backed by a warranty tailored to solar protection applications.
VISIBLE LIGHT TRANSMITTANCE (TV) (700 F,900 F,1100)
- 10%, 1%
- 7%, 1%
- 6%
SOLAR REFLEXION (RS) (700 F,900 F,1100)
- 77% , 65%
- 80% , 65%
- 81%
UV TRANSMITTANCE
0%
WARRANTY
12 Years
TENSEO EDITION TXS SERIES: LIGHTWEIGHT MEMBRANE FOR SHADE STRUCTURES
FEATURES
- UV protection
- Performance
- Lightweight
ROLL LENGTH
200 lm (218.72 yd)
WIDTH
300 cm (118 in)
RELIABILITY AND SIMPLICITY FOR SHADE PROJECTS
The TXS range meets the needs of shade projects requiring a reliable, cost-effective, and easy-to-install solution. It combines solar protection, durability, and operational performance with an excellent strength-to-weight ratio.
VISIBLE LIGHT REFLEXION (RV) (700 F,900 F,1100)
- 89% , 68%
- 92% , 68%
- 92%
FIRE RESISTANCE
B-s2,d0/EN 13501-1
SUPPORT CLOTH
Multifilament polyester
SOLAR TRANSMITTANCE (TS) (700 F,900 F,1100)
- 11% , 4%
- 8% , 3%
- 7%
WIDTH (700 F,900 F,1100)
- 700 g/m² (21 oz/sq. yd)
- 900 g/m² (27 oz/sq. yd)
- 1,100 g/m² (32 oz/sq. yd)
TEAR STRENGTH (WARP/WEFT) (700 F,900 F,1100)
- 35/35 daN (79/79 lbs)
- 45/45 daN (101/101 lbs)
- 85/75 daN (191/169 lbs)
THICKNESS
- 700 F : 0.55 mm (550 microns)
- 900 F : 0.75 mm (750 microns)
- 1100 F : 0.95 mm (950 microns)
COLORS
MANAGEMENT SYSTEMS
- Quality: ISO 9001
- Environment: ISO 14001
- Energy: ISO 50001
ITEM CODE
- 700 F : B4907
- 900 F : B4616
- 1100 F : B4911
HEAT TRANSFER COEFFICIENT (VERTICAL/HORIZONTAL) CALCULATED
- 700 F : U=5.6 / 6.4 W/sqm/°C,
U=5.6 / 6.4 W/sqm/°C
- 900 F : U=5.6 / 6.4 W/sqm/°C,
U=5.6 / 6.4 W/sqm/°C
- 1100 F : U=5.6 / 6.4 W/sqm/°C
TENSILE STRENGTH (WARP/WEFT)
- 700 F : 320/300 daN/5 cm (360/337 lbs/in)
- 900 F : 420/410 daN/5 cm (472/461 lbs/in)
- 1100 F : 560/520 daN/5 cm (629/585 lbs/in)
PERFORMANCE, LIGHT WEIGHT, AND UV PROTECTION
- Effective UV protection
- Controlled light transmission
- Lightweight membrane, easy to install
- Well-balanced mechanical strength and flexibility
- PVDF treatment for enhanced long-term performance
- Multiple weights available to meet project requirements (700 to 1100 g/m²)
