Kratki Water Heating Fireplace Kratki Maja 8 Kw Ø 180
WATER HEATING FIREPLACE KRATKI MAJA 8 KW Ø 180
WATER HEATING FIREPLACE KRATKI MAJA 8 KW Ø 180
Ecological Combustion
The unit meets the requirements of Ecodesign standards and the restrictions of the BImSchV 2 standard, which determines the maximum CO emission.
INFORMATION
BASE MATERIAL
- Steel
- Cast iron
BRAND
Kratki
PRODUCT TYPE
Fireplace
SAFETY AT THE HIGHEST LEVEL
- Perfect tightness thanks to the solid welds made in a noble gas shielding.
- All steel elements are laser cut and bent on CNC bending machines.
- Protection against overheating by the built-in coil pipe - connector input / output 1/2”.
SKU
MAJA/PW/12/W
EAN
5901350026151
EQUIPMENT
Ashpan
ENERGY CLASS
A
CERTIFICATIONS / COMPLIANCE
- Ecodesign
- BImSchV 2
CO EMISSION (AT 13% O2) ≤ GIVEN IN %
0.098
POLLEN EMISSION (MG/M3)
31
EEI
106
HEAT OUTPUT FOR SPACE HEATING
2 kW
EMISSION
- CO emission : 1235 mg/m3
- NOx emission : 140 mg/m3
- OGC emission : 63 mg/m3
DIAMETER OF THE FLUE GAS OUTLET
180
FUEL TYPE
Seasoned deciduous wood (humidity ≤20%)
MINIMUM REQUIRED ACTIVE FIELD OF OUTLET GRILLES
120 cm2
AVERAGE POWER FROM WATER
6 kW
SEASONAL ENERGY EFFICIENCY
70 %
POWER
- Nominal power : 8 kW
- Heating power range : 3.5 - 10 kW
WEIGHT
109 kg
ADDITIONAL CLOSING
No
CONVENIENT TO USE
- Movable grate and ashpan enables to clean the insert.
- Decorative fence helps to maintain the tidiness and protects against falling out of wood.
- The cold handle system which limits the risk of burns due to the possibility of removing it while burning.
- Classic front of insert is equipped with a heat-resistant ceramics that can withstand temperatures up to 660°C.
DIMENSIONS
- Width : 60 cm
- Height : 67.7 cm
- Depth : 39 cm
MAX WORKING PRESSURE (BAR)
2
THERMAL EFFICIENCY
80 %
WATER CAPACITY (L)
18
MINIMUM REQUIRED ACTIVE AREA OF INLET GRILLES
60 cm2
MAX BILLET LENGTH
33 cm
DOOR OPENING
Left
FLUE GAS TEMPERATURE
236 °C
MAXIMUM USE OF ENERGY
- Regulation of chimney draft using built-in damper.
- Increased heat exchange surface due to built-in smoke tubes and high flue.
- Built in smoke tubes and high flue, which increase the heat exchange surface.
- Manual control over the combustion process carried out by ash tray regulator.
- The body and the front of the insert are resistant to high temperatures thanks to the high quality steel used in production.
