GRAVITY SEWER PIPE WITH 200 PSI STIFFNESS
GRAVITY SEWER PIPE WITH 200 PSI STIFFNESS
Truss pipe® is a thermoplastic composite, double-wall pipe with concentric inner and outer walls braced by a truss-type structure. The truss voids are filled with lightweight mearlcrete for additional stiffness and compressive strength.
INFORMATION
BRAND
Contech
PRODUCT TYPE
Pipes
TRUSS PIPE APPLICATIONS
- Sanitary sewers
- Leachate collection systems
- Roadway/runway underdrains
- House service and lateral pipes
TRUSS PIPE JOINTS
- Gasketed joint
- Solvent-weld joints meet ASTM D3212 or ASTM 2680 performance requirements
DETAIL
Traditional rigid pipe materials can rupture when subjected to non-uniform loading, as they lack the ability to adjust to trench load variations. TRUSS PIPE combines high stiffness with flexibility; allowing it to resist variable loads while maintaining shape control. And with more than forty years of in-service use and hundreds of millions of feet installed, TRUSS PIPE is the unchallenged performer.
COVER
One Feet
STIFFNESS
200 psi
MATERIAL
Pvc
USE
Construction
TRUSS PIPE PROPERTIES
- Standard length is 12.5’
- Available in 8”, 10”, 12”, and 15” diameters
FLOW RESISTANCE
TRUSS PIPE’s glossy smooth interior with a Manning’s “n” value of 0.009 reduces internal flow resistance.TRUSS PIPE can be installed in variable trench conditions to more than 40 feet and withstand H-20 live loading with less than one feet of cover.Its strength, stiffness, joint tightness, durability, and economy have made TRUSS PIPE the choice for engineers, specifiers, and contractors.
COLLECTION
Gravity
ENVIRONMENT
Indoor
WALL
Double Wall
STRUCTURE
Truss-type
BENEFITS
-Excellent resistance to chemicals found in sanitary systems, including acids, alkalis, and salts -Unparalleled deflection control -Flexible; resists variable loads while maintaining shape control -Superior hydraulics; reduces internal flow resistance -Extremely low infiltration rates
FEATURES
-Made from thermoplastic PVC -200 psi minimum pipe stiffness -Unique double-wall pipe with concentric inner and outer walls braced by a truss-type structure -Manning’s “n” of .009 -Watertight joints
RESULT
The result is a semi-rigid pipe that provides 200 psi minimum pipe stiffness and unparalleled deflection – the ideal thermoplastic gravity sewer PVC pipe.
TRUSS PIPE FOR SANITARY SEWERS
When you’re looking for pipe strength on a demanding sewer project, TRUSS PIPE is the solution. Compared in strength to pipes like Ductile Iron and C-900, TRUSS PIPE® offers strength, durability, and reliability at a fraction of the cost.
