OTAZU ECO FIREPLACE
OTAZU ECO FIREPLACE
It’s a compact heating fireplace equipped with an imposing, fully glazed front. OTAZU is versatile to adapt to your needs.
FEATURES
CLEANING ACCESS
Easy access for sweeping via a hatch (patented). Deflectors easy to dismantle
by hand without tools.
PERFECT COMBUSTION
Optimum burning technology which achieves great combustion efficiency. Lower consumption and greater autonomy of firewood loads.
EXTERNAL AIR INLET
Ductable-air system which draws in air from outside the home for combustion. Suitable for energy-efficient homes.
INFORMATION
PRODUCT TYPE
Fireplace
EMISSIONS CO
0.09 %
HEATING VOLUME
433 m3
HEATING AREA
173 m2
HEAT OUTPUT RANGE
14-26 kW
NOMINAL HEAT OUTPUT
20.0 kW
EFFICIENCY
84.5 %
COLLECTION
Otazu
DIMENSIONS
- Length : 1135 mm
- Width : 780 mm
- Depth : 516 mm
FIREBOX DIMENSIONS
- Width : 604
- Depth : 470
- Length : 412 mm
WEIGHT
155 kg
FLUE SOCKET
ø200 mm
FIREPLACES
Wood boiler fireplaces
FIREWOOD MEASUR
55 cm
DETAIL
It can include a refractory interior, a cooling system for added safety and an exterior insulation kit. The air inlet required for combustion can be ducted in from outside, creating an airtight system.
GLASS
Anti-stain
AIR DUCTING
Outdoor
FIREBOX MATERIAL
Refractory
PRODUCTION
Made in Spain
EXTRA CLEAN GLASS
New air-intake-to-glass system to keep the glass cleaner for longer.
OUTER MATERIAL
Steel
CHIMNEY SWEEPING
Easy
FIRE VISION
High
COMBUSTION
Optimal
