Lacunza INCA 80 Fireplace
INCA 80 FIREPLACE
INCA 80 FIREPLACE
The INCA series monobloc stand outs for its simple installation. Its horizontal vision will let you enjoy a panoramic view of the fire.
FEATURES
CLEANING ACCESS
Easy access for sweeping via a hatch (patented). Deflectors easy to dismantle
by hand without tools.
EOLO SYSTEM
High-pressure ventilation system with centrifugal turbines and speed regulator (control unit) or fans which allows you to heat different rooms in the home via ducts.
EASY FIRE CONTROL
Fire control system with which to regulate optimum combustion and clean wood-burning appliances using a single control.
DOUBLE COMBUSTION
Technology to burn the gas generated during the initial combustion of firewood. More efficient, longer autonomy and lower consumption.
PERFECT COMBUSTION
Optimum burning technology which achieves great combustion efficiency. Lower consumption and greater autonomy of firewood loads.
INFORMATION
HEAT OUTPUT RANGE
11-20 kW
BRAND
Lacunza
PRODUCT TYPE
Fireplace
NOMINAL HEAT OUTPUT
15 kW
EXTRA CLEAN GLASS
New air-intake-to-glass system to keep the glass cleaner for longer.
PARTICLES
11 mg
FLUE SOCKET
ø200 mm
EMISSIONS CO
0.07 %
WEIGHT
180 kg
DIMENSIONS - FIREBOX
- Width : 640 mm
- Height : 525 mm
- Depth :360 mm
DIMENSIONS - TOTAL
- Width : 826 mm
- Height : 1154 mm
- Depth : 646 mm
EXTERNAL AIR INLET
Ductable-air system which draws in air from outside the home for combustion. Suitable for energy-efficient homes.
EFFICIENCY
82.0 %
FLUE SOCKET
ø200 mm
FIREWOOD MEASURE
60 cm
OGC EMISSIONS
47 mg
HEATING AREA
133 m2
NOX EMISSIONS
89 mg
ENERGY LABEL
FIREBOX MATERIAL
- Vermiculite
- Thermote
OUTER MATERTIAL
Steel
HEATING VOLUME
333 m3
FEATURES
- Grate
- Ashtray
- Deflector
- Silent mode
- Anti-stain glass
- Simple operation
- Outdoor air ducting
- Double Combustion
- Optimal combustion
- Easy chimney sweeping
- Speed control and air direction
