Nelskamp Double-trough Grooved Tile D 13 Ü
DOUBLE-TROUGH GROOVED TILE D 13 Ü
DOUBLE-TROUGH GROOVED TILE D 13 Ü
The D 13 Ü recreates the classic form of the double-trough grooved tile in a larger format.
Around 12 tiles per square metre are quickly installed. This tile is used for both new buildings and modernisation projects.
INFORMATION
PRODUCT TYPE
Roof Tiles
BRAND
Nelskamp
COLLECTION
Double-trough
PRODUCTION
Made in Germany
TOTAL WIDTH
25.5 cm
TOTAL LENGTH
43.9 cm
USE
Outdoor
TILE FORMAT
Large
AVAILABLE COLORS
6
STANDARD ROOF PITCH
- 30° with offset course installation
- 25° with broken bond installation
WEIGHT PER TILE
3.6 kg
WEIGHT PER SQM
Min. 45.36 kg
INTERLOCKING ROOFING
Pressed interlocking roofing tile in compliance with DIN/EN 1304
BENEFITS
- Waterproof
- Frost-resistant
- Breathable
AVERAGE TILLING WIDTH
21.5 cm
AVERAGE TILLING LENGTH
36.8 cm ± 12 mm
TILES REQUIRED PER SQM
12.2 - 13.1 pcs.
COLOURS & SURFACES
COLOURS & SURFACES
-Dark Brown, Engobed (Glazed) -Black, Gloss Engobed (Glazed) -Antique No. 2, Engobed -Old Black, Engobed -Natural Red -Red, Engobed
