Serge Ferrari Soltis 502 Proof
SOLTIS 502 PROOF
SOLTIS 502 PROOF
Waterproof membrane, unfaltering resistance
INFORMATION
WEIGHT EN ISO 2286-2
590 g/m² ( 17.4 oz/sq. yd)
BRAND
Sergeferrari
PRODUCT TYPE
Composites
THICKNESS
0.45 mm (450 microns)
COLLECTION
Soltis
WIDTH
180 cm (70.9 in)
COMPOSITION
100% recyled PET yarns / Coating PVC
DESIGN FREEDOM AND DURABILITY WITH SOLTIS 502 PROOF
Available in a wide color palette and featuring a unique satin finish that gives projects a modern, premium look, Soltis 502 Proof offers great architectural freedom and aligns with current design trends. Its exceptional durability and easy maintenance make it a cost-effective long-term solution and a reliable protection against heat and weather for year-round comfort.
QUALITY
ISO 900
DOWNLOAD
↓ Brochure
MANAGEMENT SYSTEMS
- Energy : ISO 50001
- Environment : ISO 14001
ENVIRONMENTAL PROPERTIES
Carbon impact EN 15804 + A1 : 2.20 kg CO2 eq/m²
WARRANTY
10-year warranty
ROLL LENGTHS
40 lm (43.74 yd)
TEAR STRENGTH (WARP/WEFT) (DIN 53.363)
25/22 daN (56/49 lbs)
TENSILE STRENGTH (WARP/WEFT) (EN ISO 1421)
220/220 daN/5 cm (495/495 lbs/2 in)
TOLERANCE
+/-5% tolerance
ENVIRONMENT
ISO 14001
APPLICATIONS
- Art and Urban Planning
- Coffee shops, hotels, restaurants
- Terraces and Outdoor Living Areas
- Lodges and outdoor hospitality
A RELIABLE AND CERTIFIED SOLUTION FOR YOUR SOLTIS 502 PROOF PROJECTS
Soltis 502 Proof benefits from the exclusive Précontraint® technology of Serge Ferrari Group, ensuring unmatched dimensional stability and excellent long-term performance. As with the rest of the Soltis range, Soltis 502 Proof is covered by a 5-year warranty. It holds ISO 9001, ISO 14001 and ISO 50001 certifications.
It is supported by an FDES/EPD assessing its environmental impact across its entire life cycle, with documentation available upon request. It also meets numerous fire standards, including Euroclass Bs2d0 classification.
HIGH-PERFORMANCE WATERPROOF FABRIC INTEGRATING 100% RECYCLED POLYESTER YARNS
Soltis 502 Proof is a waterproof technical membrane designed for outdoor solar protection applications (shade sails, fixed pergola roofs, pergola vélums or retractable pergola roofs). Manufactured using 100% recycled high-tenacity polyester yarns, Soltis 502 Proof makes no compromise on quality. It even improves its level of mechanical resistance while reducing its carbon footprint (nearly 30% lower compared with previous versions). Soltis 502 Proof is available in 35 redesigned colors combining neutral, natural, vibrant and energetic tones. In 2025, it received a MIAW Innovation Award from the architecture and design magazine Muuuz.
COLORFUL, DURABLE, WATERPROOF MEMBRANE MADE WITH 100% RECYCLED POLYESTER YARNS
-Waterproof -Recycled Content Base -Wide Range Of Colors -UV Protection
-Dimensional Stability
PROVEN PERFORMANCE FOR DEMANDING OUTDOOR PROJECTS
Designed to last, Soltis 502 Proof combines multiple technical advantages that ensure performance, aesthetics and durability for all demanding outdoor applications:
- Glare control
- Excellent tear resistance
- Excellent UV color fastness
- Complete waterproofness
- Flexibility and strength offering total design freedom
- Smooth finish for easy maintenance, combined with an antifungal treatment
Thanks to the Précontraint® technology, the fabric does not tear and does not stretch, ensuring the long-term durability of structures. It provides lasting resistance to UV exposure thanks to a rigorous selection of pigments and a coating thickness greater than the yarn crest for enhanced protection.
COLORS
COLORS
