Apton Linear Strip Ceiling AP 103
LINEAR STRIP CEILING AP 103
LINEAR STRIP CEILING AP 103
AP 103 linear strip ceiling adds decorative style and modernity with square-edge strips.
The closed and open panel strips offer flexibility in design, allowing you to choose the desired channel appearance based on your decoration needs. Installation is made easy with sets of clips, hanging wires, and metal ceiling strips.
INFORMATION
BRAND
Apton
COLLECTION
Linear
ACOUSTIC INLAY
Black non-woven acoustic fleece as standard
PERIMETER SOLUTION
Standard perimeter trim in steel and aluminium available
PRODUCT TYPE
Ceiling
PRODUCTION
Made in United Kingdom
TILE MATERIAL
Galvanised steel sheet (Aluminium or other materials on request)
COATING
Powder coated finish
FIRE PERFORMANCE
Fire Class : A1 (EN 13501-1)
ACOUSTIC
- Sac Aw : Up To 1.00
- Sri Rw : Up To 53.8db
HUMIDITY
- Galvanised : 90% RH
- Aluminium : 100% RH
STANDARD MODULES
- 50 mm
- 100 mm
- 200 mm
- 300 mm
PERFORATION
- D. 1.5mm
- D. 1.8mm
- D. 2.5mm
GRID SYSTEM
AP103 Carrier System
DOWNLOAD
↓ Data Sheet
LIGHT REFLECTION
- Plain Panel 86%
- Perforated Panel 72%
(RAL 9010, 20 Gloss)
