TENSEO XTREM TX30 SERIES
TENSEO XTREM TX30 SERIES
Tenseo Xtrem TX30: durable PVC membrane for translucent roofs and envelopes.
INFORMATION
BRAND
Sergeferrari
PRODUCT TYPE
Solar Shading
TEAR STRENGTH (WARP/WEFT)
55/50 daN (124/112 lbs) DIN 53.363
TENSILE STRENGTH (WARP/WEFT)
430/430 daN/5 cm (967/967 lbs/2 in)
HIGH-PERFORMANCE PVC
Tenseo Xtrem is a high-performance PVC membrane delivering durability, dimensional stability, and excellent light transmission. Thanks to exclusive precontraint technology, it ensures a service life of over 30 years.
BASE
Slack is removed from base-cloth yarn and tension equalised in both warp and weft
COLLECTION
Tenseo
WARRANTY
20-year warranty
PROTECTIVE COATING
A flatter base-cloth profile offers significantly more PVC protective coating over the crest of the weft yarn
ROLL LENGTH
250 lm (273.40 yd)
ASSEMBLY
Weldable after abrasion
MICRO ORGANISM RESISTANCE (EN ISO 846 METHOD A)
Degree 0, excellent
THE IDEAL SOLUTION FOR LARGE, DURABLE ROOFS AND FAÇADES
- Ideal for large-scale structures: stadiums, halls, and permanent buildings.
- A rare combination of durability, brightness, low maintenance, and long-lasting aesthetic quality.
WIDTH
178 cm (70.1 in)
THICKNESS
0.78 mm (780 microns)
PROVEN DESIGN LIFE
Proven design life > 30 years
VISIBLE LIGHT REFLEXION (RV)
84%
YARN
High tenacity Polyester 1100 Dtex Low wick treatment for anticapillarity
ADHESION EN ISO 2411
12 daN/5 cm (27 lbs/2 in)
WEIGHT
1050 g/m² (31 oz/sq. yd)
FLAME RETARDANCY
- NFPA 701 Method 2
- CSFM T19 AS/NZS 1530.3
- AS/NZS 3837 B-s2,d0/EN 13501-1
COMPATIBILITY AND CERTIFICATIONS
- Certifications: ISO 9001, ISO 14001, ISO 50001
- Benefits: enhances natural daylight, reduced maintenance, long-lasting aesthetics.
KEY FEATURES
- Uniform translucency (Visu Service).
- Long service life with 30-year coating and Crosslink topcoat.
- Exceptional dimensional stability (precontraint technology).
- Enhanced UV protection and very easy-to-clean surface.
- Excellent mechanical strength depending on the version.
DOWNLOADS
↓ Brochure
RESIDUAL ELONGATION
<0.4%/<0.4% (EN 15977)
