Apton Ap102 Clip In Ceiling Information
AP102 CLIP IN CEILING INFORMATION
AP102 CLIP IN CEILING INFORMATION
Apton’s AP 102 Clip in Ceiling features tiles manufactured to fine press tool tolerances that are effortlessly clipped into a concealed grid system.
Automatic levelling is achieved through unique twin pip arrangements pressed into the flanges during manufacturing, ensuring a streamlined appearance.
INFORMATION
BRAND
Apton
COLLECTION
Clip
TILE MATERIAL
Galvanised steel sheet (Aluminium or other materials on request)
ACOUSTIC INLAY
Black non-woven acoustic fleece as standard (other options available on request)
COATING
Powder coated finish
PRODUCT TYPE
Ceiling
PRODUCTION
Made in United Kingdom
LIGHT REFLECTION
- Plain Panel 86%
- Perforated Panel 72% (RAL 9010, 20 Gloss)
ACOUSTIC
- SAC aw : up to 1.00
- SRI Rw : up to 53.8dB
MANUFACTURING
Fine Press Tool
GRID SYSTEM
AP102 Clip-In Grid System
HUMIDITY
- Galvanised 90% RH
- Aluminium 100% RH
SHAPE
Tiles Are Available With A Square Edge, Incorporating A Hinging Tab And pip Locating Details
FIRE PERFORMANCE
Fire Class: A1 (EN 13501-1)
DOWNLOAD
↓ Data Sheet
PERFORATION
- D. 1.5mm
- D. 1.8mm
- D. 2.5mm
PERIMETER SOLUTION
Standard perimeter trim in steel and aluminium available
