Apton Lay In Ceiling AP 101
LAY IN CEILING AP 101
LAY IN CEILING AP 101
Our AP 101 Lay in Ceiling Tiles are expertly crafted for easy installation in a conventional T grid system. This 100% accessible modular ceiling system features flat and recessed lay-in and lay-on tiles, perfect for areas needing regular maintenance.
INFORMATION
BRAND
Apton
COLLECTION
Lay
PRODUCTION
Made in United Kingdom
PRODUCT TYPE
Ceiling
GRID SYSTEM
- AP101 T24mm
- AP101 T15mm Grid System
COATING
Powder coated finish
FIRE PERFORMANCE
Fire Class: A1 (EN 13501-1)
STANDARD MODULES
- 600mm x 600mm
- 600mm x 1200mm
- 1200mm x 1200mm
TILE MATERIAL
Galvanised steel sheet (Aluminium or other materials on request)
USE
Construction
DOWNLOAD
↓ Data Sheet
PANELS
The adaptable AP 101 Lay in ceiling panels suit different exposed grid systems, including T24 and T15mm.
ACOUSTIC
- SAC aw : up to 1.00
- SRI Rw : up to 53.8dB
ACOUSTIC INLAY
Black non-woven acoustic fleece as standard
PERFORATION
- D. 1.5mm
- D. 1.8mm
- D. 2.5mm
SHAPE
Tiles are square with out-turned
flanges laid onto the exposed grid system.
LIGHT REFLECTION
- Plain Panel 86%
- Perforated Panel 72% (RAL 9010)
ENVIRONMENT
Indoor
HUMIDITY
- Galvanised 90% RH
- Aluminium 100% RH
PERIMETER SOLUTION
Standard perimeter trim in steel and aluminium available
