MOVABLE GLASS WALL SYSTEMS
MOVABLE GLASS WALL SYSTEMS
ComfortDrive® Automated Self-Driving Panel System
Daylighting and automation are two highly desired features of movable glass walls.
With the ComfortDrive® Automated Self-Driving Panel System, glass panels can be moved to pre-programmed positions under fully-automated control with a user-friendly touchpad.
INFORMATION
BRAND
Modernfold
PRODUCT TYPE
Movable Walls
OPERATION
Single Panel Automatic - Touchpad
TRACK OPTIONS
ComfortDrive® Automated System
MODELS
- PureView® on ComfortDrive®
- Acousti-Clear® Motorized on ComfortDrive®
MATERIAL
Glass
PRODUCTION
Made in USA
SYATEM
The ComfortDrive® system brings together the beauty of glass operable walls with state-of-the-art automation to exceed any set of expectations.
GLASS THICKNESS
- PureView® on ComfortDrive® : 1/2" (13 mm)
- Acousti-Clear® Motorized on ComfortDrive® : 5/16" (8 mm)
3/8" (9.5 mm)
RAIL HEIGHT & DESIGN
- Acousti-clear® motorized on comfortdrive® : 4.6875" (119 mm) Horizontal
- PureView® on ComfortDrive® : 4.12" (105 mm) Square Bottom & Top 10" Square Bottom
MAXIMUM HEIGHT
12' (3658 mm)
MAXIMUM PANEL WIDTH
4' (1219 mm)
CLOSURE METHOD
- PureView® on ComfortDrive® : Auto Pivot, STD Intermediate Panel
- Acousti-clear® motorized on comfortdrive® : Auto Glass Expandable, AWA, Manual Pivot, Auto Pivot
MAXIMUM PANEL WEIGHT
- PureView® on ComfortDrive® : 330 lbs. (150 kg)
- Acousti-clear® motorized on comfortdrive® : 550 lbs. (250 kg)
GLASS OPTIONS
- PureView® on ComfortDrive® : Low Iron, Frosted, Etched, Applique, Polar White Markerboard Glass, Laminated
- Acousti-clear® motorized on comfortdrive® : Low-Iron, Frosted, Clear High STC, Low-Iron High STC, Frosted High STC, MorphGlas™
PANELS
Glass Wall Panels
STANDARD GLASS
Clear & Tempered
RAIL FINISH OPTIONS
- PureView® on ComfortDrive® : Clear Anodized, Dark Bronze Anodized, Black Anodized, Satin Stainless Anodized, Powder Coat Std RAL
- Acousti-clear® motorized on comfortdrive® : Clear Anodized, Satin Stainless Anodized, Powder Coat White or Black, Powder Coat STD RAL
DETAIL
FLEXIBLE SPACES
Bringing Daylighting and Automation into Flexible Spaces with Moving Glass Wall Systems
The ComfortDrive® Automated Self-Driving Panel System provides outstanding convenience and flexible space utilization when combined with the beauty and daylighting benefits of Acousti-Clear® and PureView® glass wall panels.
ComfortDrive® supports up to 30 panels on 164' track and speeds up to 30 ft./min. Each panel is custom-programmed via our smart control system. Trolleys on panels communicate with the control box in motion. A high level of safety is ensured with an integrated monitoring system that stops and reverses the panel in contact with an obstacle.
Various design and acoustic options include 51 STC acoustical control with Acousti-Clear® Motorized and single pane flexibility with PureView®.
Bring high-end aesthetics and touchpad operation to your interior space today with Modernfold’s ComfortDrive® Automated Self-Driving Panel System. Space management will never be the same.
