BRIDGE PLANK BRIDGE DECK
BRIDGE PLANK BRIDGE DECK
Cost-Effective Installation for Deck Rehab/ New Construction. Contech Bridge Plank is used for re-decking bridges and for new construction, either to replace deteriorated wood or concrete decks on otherwise structurally sound bridges, or as a high-strength continuous bridge deck surface for new bridges.
Once welded or bolted in place, Contech Bridge Plank restores strength to old structures and stiffens bridges laterally, providing a solid base for new asphalt paving and eliminating rattles.
With Contech Steel Bridge Plank, there is nothing to crack, warp or rot. Repeated, expensive repair work on the bridge floor comes to a halt, and the danger of fire is minimized. Our Bridge Plank also eliminates reduced load limits caused by inadequate flooring.
INFORMATION
BRAND
Contech
PRODUCT TYPE
Bridge
CONVENIENT
Convenient lengths and standard sizes with no special equipment or training - Fast, low-cost installation
GALVANIZED STEEL PLANKS
Long service life with minimal maintenance
RIGID PANEL CONSTRUCTION
Restores strength to old structures. Positive welded connections help stiffen the entire structure and the deck becomes an integral part of the bridge
HIGH STRENGTH-TO-WEIGHT RATIO
Total weight is only slightly higher than most timber floors and in some cases (especially replacement of reinforced concrete decks) the load is actually reduced
COLLECTION
Bridge Plank
USE
Outdoor
BRIDGE PLANK FOR DECK REHABILITATION
The easy and economical solution is to replace noisy, worn-out wood floors or deteriorated concrete decks with Contech Bridge Plank. Corrugated steel Contech Bridge Plank has a proven track record from coast to coast on many types of bridges, including skewed structures.
FEATURES
Contech Steel Bridge Plank comes in different corrugation patterns to fit various deck loading requirements. Installation requires no special crews or equipment.
The structural-quality steel used to manufacture our Bridge Plank conforms to the requirements of ASTM A 1011, ASTM A 929, ASTM A 653 or ASTM A 1018, depending on the steel thickness. Zinc coatings, when ordered, are in accordance with ASTM A 123 (for hot-dip galvanized) or ASTM A 929 (for Pre-galvanized or Aluminized Type 2).
ADVANTAGES
COST ESTIMATES
We can quickly provide engineer’s cost estimates to assist with your solution selection process.
AGENCY/REGULATORY GUIDANCE
Our team is ready to provide you with expert advice and assistance on local regulatory requirements, resulting in faster approvals.
SOLUTION DEVELOPMENT
Our engineers can review your requirements, weigh all options, and recommend the optimal solution to integrate with your site designs.
SITE SPECIFIC DRAWINGS
Our engineers can provide site-specific drawings for proposals, project meetings, and submittals, helping you be more efficient with your time.
TECHNICAL EXPERTISE
Our engineers can assist by providing product specific engineering calculations such as hydraulics, buoyancy, foundation reactions, and unit sizing.
ON-SITE ASSISTANCE
Contractors know time is money, so we provide preconstruction meetings, delivery coordination, and on-site installation support to ensure a timely, smooth installation.
