Sergeferrari Precontraint 1002 S2 Shading Structures
PRECONTRAINT 1002 S2 SHADING STRUCTURES
PRECONTRAINT 1002 S2 SHADING STRUCTURES
Tenseo Advanced 1002 S2 combines long life, consistent color translucency and easy maintenance. This Type II membrane is suitable for shade structures and sports hall roofs
INFORMATION
COMPLEMENTARY INFORMATION
- Residual elongation EN 15977 : <0.5% / <0.5%
- Surface treatment (top/back) : S2 architectural varnish / PVDF
- Elongation 24 h -10 daN/5 cm (warp/weft) EN 15977 : <1.2% / <1.2%
- Yarn : High tenacity Polyester 1100 Dtex - Low wick treatment for anticapillarity
BRAND
Sergeferrari
PRODUCT TYPE
Shading Structures
DETAIL
- Sport hall roofs
- Shading structures
- Covered outdoors
COLLECTION
Precontraint
WARRANTY
15 years
COLOR
White : 1002-8636-S2
DOWNLOAD
↓ Brochure
PRODUCTION
Made in France
MANAGEMENT SYSTEMS
- Quality : ISO 9001
- Energy : ISO 50001
- Environment : ISO 14001
FIRE RESISTANCE
- AS/NZS 1530.3
- NFPA 701 Method 2
- CSFM T19 B-s2,d0/en 13501-1
- AS/NZS 3837 B-s2,d0/EN 13501-1
APPLICATIONS
- Shade Structures
- Open Air Roofing
FEATURES
- Long lasting and low maintenance
- Controled color per translucency (VISU service)
- High dimensional stability due to Précontraint® technology
MECHANICAL PROPERTIES
- Adhesion EN ISO 2411 : 12 daN/5 cm • 27 lbs/2 in
- Tear strength (warp/weft) DIN 53.363 : 55/50 daN • 80/75 lbs
- Tensile strength (warp/weft) en iso 1421 : 420/400 daN/5 cm • 480/450 lbs/2 in
ACCESSORIES
We recommend using serge ferrari detergent to clean precontraint membranes
SERVICES
- Short production runs
- Special production and colours
- 50 lm rolls available upon request
- Verification of consistent color per translucency (VISU service)
Tenseo advanced 1002 s2 is the new name of the products formerly known as flexlight advanced 1002 s2.
WIDTH
267 cm • 105.1 in
WEIGHT EN ISO 2286-2
1.050 g/m² • 31 oz/sq. yd
ADVANTAGES
THERMAL, OPTICAL AND ACOUSTIC VALUES
- Solar factor (g) EN 410 : 9.5%
- UV transmittance EN 410 : 0%
- Solar Reflexion (Rs) EN 410 : 81%
- Visible light Reflexion (Rv) EN 410 : 90%
- Solar Transmittance (Ts) EN 410 : 6%
- Visible light Transmittance (Tv) EN 410 : 4%
- Visible light Transmittance (Tv) NFP 38511 : 8%
- Acoustic weakening index ISO 140-3 & ISO 717-1 : 14 dBA
- Solar Reflectance Index (SRI) ASTM E1980-01 (Approach II) : >95%
- Heat transfer coefficient (vertical/horizontal) Calculated : U=5.6 / 6.4 W/sqm/°C
ROLL LENGTH
175 lm • 191.38 yds
TECHNOLOGY
Précontraint ® Technology
THICKNESS EN ISO 5084
0.78 mm • 780 microns
