Cavatorta Panoplax 2 Fences
PANOPLAX 2 FENCES
PANOPLAX 2 FENCES
Safety - Elegance - Simplicity
Fencing in electro-welded modular panels made out of plastic coated steel wires on galvanized core, with rectangular shaped mesh, horizontal reinforcement bends and defensive barbs on the upper part.
Posts in profiled steel with triangular shape extracted from zinc coated sheeting Z 275, plastic coated green colour, with blocks on the inner side for mounting panels and caps welded to the heads. The Panoplax2 + Profilplax system is particularly indicated for fencing in residential, commercial and industrial areas.
INFORMATION
BRAND
Cavatorta
PRODUCT TYPE
Fencing
REINFORCEMENT RIBS
Horizontal Wires
MESH
Electro Welded Panels
PACKAGES
Panoplax2 + Profilplax are respectively sold in packages of 50 and 60 pieces each.
COLLECTION
Panoplax 2
PRODUCTION
Made in Italy
SUITABLE FOR
Panoplax2 fulfils all the requirements of high grade professional fencing but is also suitable for the DIY market.
PANEL LENGTH
200 mm
COATING
Zinc and PVC
APPLICATIONS
Residential and industrial areas fences
SCREW
The system allows the post and panel to be fitted together without the use of screws and bolts, which prevents bothersome vibrations and makes installation easier.
WIRES DIAMETER
4.00 mm
COLOR
Bright Alps Green
STEEL WIRE THICKNESS
The thickness of the steel wire, the modular post, the innovative post/panel blocking system, the depth of the horizontal bends and the climb prevention barbs make the fence robust and solid.
BENDS
Horizontal Bends
ANTI-CLIMBING SPIKES
On Every Model
FITTING
The horizontal bends, the shape of the mesh, the modular fitting between post and panel, the perfect plastic coating all combine to give an extremely attractive product.
DOWNLOAD
↓ Data Sheet
SHAPE
Rectangular
ACCESSORIES
-Metallic flaps for blocking the panels (2 pre-cut pieces at the base of the pole) -Metallic sleeve strap with 4 holes in alpine green color for fixing the pole onto bases in walls or floors -Pliers for rapid easy insertion of the blocking flaps
TECHNICAL DATA
PANELS
| HEIGHT CM | LENGTH CM | MESH SIZE MM | KG EACH | KG/M2 | HORIZONTAL BENDS N DEGREE | PACKAGE KG EACH | PVC WIRE MM | H BARBS MM |
|---|---|---|---|---|---|---|---|---|
| 103 | 200 | 100x50 | 6.6 | 3.20 | 3 | 330 | 4.00 | 22.00 |
| 123 | 200 | 100x50 | 7.8 | 3.17 | 3 | 390 | 4.00 | 22.00 |
| 153 | 200 | 100x50 | 9.6 | 3.14 | 4 | 480 | 4.00 | 22.00 |
| 203 | 200 | 100x50 | 12.6 | 3.10 | 5 | 630 | 4.00 | 22.00 |
POSTS
| HEIGHT CM | CROSS SECTION MM | THICKNESS MM | KG EACH | PCS/BUNDLE N DEGREE |
|---|---|---|---|---|
| 63 | 50 | 1.2 | 1.3 | 6 |
| 103 | 50 | 1.2 | 2.0 | 6 |
| 123 | 50 | 1.2 | 2.3 | 6 |
| 153 | 50 | 1.2 | 3.0 | 6 |
| 173 | 50 | 1.2 | 3.3 | 6 |
| 203 | 50 | 1.2 | 3.7 | 6 |
| 230 | 50 | 1.2 | 4.4 | 6 |
| 250 | 50 | 1.2 | 4.7 | 6 |
