FLEXLIGHT XTREM TX30-II SHADING STRUCTURES TRANSLUCENT ROOFS

Sergeferrari Flexlight Xtrem Tx30-ii Shading Structures Translucent Roofs

FLEXLIGHT XTREM TX30-II SHADING STRUCTURES TRANSLUCENT ROOFS

Tenseo Xtrem TX30-II is a very high performance membrane, thanks to its crosslink technology. This material is ideal for complex projects involving translucent roofs.

INFORMATION

BRAND

Sergeferrari

PRODUCT TYPE

Glulam Structures

ACCESSORIES

We recommend using Serge Ferrari detergent to clean Tenseo membranes

SERVICES

Tenseo Xtrem TX30-II is the new name of the products formerly known as Flexlight TX30-II Xtrem.

WEIGHT EN ISO 2286-2

1050 g/m² (31 oz/sq. yd)

COLLECTION

Flexlight

WARRANTY

20 years

Sergeferrari Flexlight Xtrem Tx30-ii Shading Structures Translucent Roofs

COLOR

White : Tx30-ii-3000

MECHANICAL PROPERTIES

- Adhesion EN ISO 2411 : 12 daN/5 cm (27 lbs/2 in)
- Tear strength (warp/weft) DIN 53.363 : 55/50 daN (124/112 lbs)
- Tensile strength (warp/weft) EN ISO 1421 : 430/430 daN/5 cm (967/967 lbs/2 in)

WIDTH

178 cm (70.1 in)

ROLL LENGTH

250 lm (273.40 yd)

APPLICATIONS

Sergeferrari Flexlight Xtrem Tx30-ii Shading Structures Translucent Roofs
Covered Playgrounds For Schools
Sergeferrari Flexlight Xtrem Tx30-ii Shading Structures Translucent Roofs
Covered Walkways
Sergeferrari Flexlight Xtrem Tx30-ii Shading Structures Translucent Roofs
Open Air Roofing

DOWNLOAD

↓ Brochure

PRODUCTION

Made in France

MANAGEMENT SYSTEMS

- Quality : ISO 9001
- Energy : ISO 50001
- Environment : ISO 14001

FIRE RESISTANCE

- CSFM T19
- AS/NZS 1530.3
- NFPA 701 Method 2
- AS/NZS 3837 B-s2,d0/EN 13501-1

COMPLEMENTARY INFORMATION

- Assembly : Weldable after abrasion
- Residual elongation EN 15977 : <0.4% / <0.4%
- Surface treatment (top/back) : CROSSLINK PVDF/PVDF
- Elongation 24 h -10 daN/5 cm (warp/weft) EN 15977 : <1% / <1%
- Micro organism resistance EN ISO 846 Method A : Degree 0, excellent
- Yarn : High tenacity Polyester 1100 Dtex - Low wick treatment for anticapillarity

TECHNOLOGY

Précontraint ® Technology

THICKNESS EN ISO 5084

0.78 mm (780 microns)

ADVANTAGES

Sergeferrari Flexlight Xtrem Tx30-ii Shading Structures Translucent Roofs
Proven Life Time Of More Than 30 Years
Sergeferrari Flexlight Xtrem Tx30-ii Shading Structures Translucent Roofs
Suitable For Use In Severe And Tropical Climates
Sergeferrari Flexlight Xtrem Tx30-ii Shading Structures Translucent Roofs
Excellent Natural Light
Transmission

THERMAL, OPTICAL AND ACOUSTIC VALUES

- Solar factor (g) EN 410 : 14%
- UV transmittance EN 410 : 0%
- Solar Reflexion (Rs) EN 410 : 75%
- Visible light Reflexion (Rv) EN 410 : 84%
- Solar Transmittance (Ts) EN 410 : 10%
- Visible light Transmittance (Tv) EN 410 : 8%
- Visible light Transmittance (Tv) NFP 38511 : 13%
- Acoustic weakening index ISO 140-3 & ISO 717-1 : 14 dBA
- Solar Reflectance Index (SRI) ASTM E1980-01 (Approach II) : >95%
- Heat transfer coefficient (vertical/horizontal) Calculated : U=5.6 / 6.4 W/sqm/°C

TOLERANCE

a +/-5%

VARIANCE

+/-10%

ROOF

Large Roofs
