SOLTIS B28100 SAFE COLOR SOLAR PROTECTION
SOLTIS B28100 SAFE COLOR SOLAR PROTECTION
Soltis B28100 Safe Color has been especially developed to meet the fire protection requirements of A2 class following DIN 4102 standard which is taken into account for high-rise buildings.
INFORMATION
BRAND
Sergeferrari
PRODUCT TYPE
Solar Protection
COLLECTION
Soltis
PRODUCTION
Made in France
THICKNESS
0.30 mm (300 microns)
PHYSICAL PROPERTIES
- Tensile Strength (Warp/weft) En Iso 1421 : 200/150 daN/5 cm • 450/337 lbs/2 in.
- Tear strength (warp/weft) DIN 53.363 : 10/10 daN • 22/22 lbs
DESIGN
Elegant
WARRANTY
5-year warranty
COATING
Coating Coated fiberglass fabric
CONFECTION
Hot bar welding & welding tape
ROLL LENGTH
In 250 cm • 98.4 in (70 lm • 76.55 yd)
FIRE RESISTANCE
Rating : A2/DIN 4102 RF1/VKF 6q.3 (AEAI)
WIDTH
250 cm (98.4 in.)
DOWNLOAD
↓ Brochure
ADVANTAGES
transmission
QUALITY
ISO 9001
ENERGY
ISO 50001
WEIGHT EN ISO 2286-2
410 g/m² • 12.1 oz/sq. yd
YARN
Fiber glass fabric (DIN 60001)
DETAIL
The increase in fire accidents, especially in high-rise buildings and tall public buildings, have led to a significant tightening of fire safety requirements in recent years. Building materials are divided into different fire behavior - and fire protection classes as part of the fire protection standard. Factors such as flammability, rate of fire spread and smoke generation are decisive for the classification. Soltis b28100 is classified rf1 following aeai requirements to match with safety regulations for buildings over
30 m height.
ENVIRONMENT
ISO 14001
AVAILABLE COLORS
5
FINISHES
547
537
PERFORMANCE
| COLOR | WIDTH 250 CM 98.4 IN | TS | RS | AS | TV n-h | gtot e * | gtot i * |
|---|---|---|---|---|---|---|---|
| B28100-537 | - | 4 | 39 | 57 | 0 | 0.02 | 0.25 |
| B28100-547 | - | 1 | 19 | 80 | 0 | 0.02 | 0.25 |
| B28100-548 | - | 8 | 50 | 42 | 5 | 0.03 | 0.18 |
| B28100-549 | - | 2 | 23 | 75 | 1 | 0.02 | 0.24 |
| B28100-558 | - | 0 | 8 | 92 | 0 | 0.03 | 0.27 |
