Falmec Monolith worktop
MONOLITH WORKTOP
MONOLITH WORKTOP
Functionality multiplied
Resting on the worktop, Monolith is an element of the most precious design, conceived in order to cater for a range of needs in the most refined way.
A handy channel equipped with suction function, that can also hold ladles, spices, knives, cutting boards and other tools, as well as electrical outlets, lends style and practicality to the kitchen.
INFORMATION
BRAND
Falmac
PRODUCT TYPE
Worktop
COLLECTION
Monolith
PRODUCTION
Made in Italy
NET WEIGHT
- Plant Basin 30 cm : 26.6 kg
- Accessory Module 60 cm : 6 kg
- Accessory Module 90 cm : 9 kg
- Accessory Module 30 cm : 3.15 kg
- Body Hood Worktop 90 cm : 26.6 kg
INSTALLATION
Worktop
MAXIMUM POWER
180 W
CONTROLS
- Touch Controls
- Dialogue system
- Remote control (optional)
FINISHES
- Black glass satin finishing
- Black anodized satin aluminium profiles
DOWNLOADS
↓ Instruction Manual.pdf
↓ Instruction manual Accessory Modules.pdf
↓ Technical specifications (Plant basin - 30 cm).pdf
↓ Technical specifications (Accessory module - 30 cm).pdf
↓ Technical specifications (Accessory module - 60 cm).pdf
↓ Technical specifications (Accessory module - 90 cm).pdf
↓ Technical specifications (Body hood - Worktop - 90 cm - Black - 800 m³/h).pdf
EAN CODE
- 8034122713632 (90 cm)
- 8034122713625 (60 cm)
- 8034122713618 (30 cm)
- 8034122713694 (30 cm)
- 8034122364698 (90 cm)
FILTERS
Metallic grease filter, removable and washable Carbon. Zeo Microtech regenerable filter (optional)
USE
Kitchen
MOTOR
Brushless Motor
VOLTAGE
220-240V 50-60Hz
FUNCTION
Extracting/Filtering
DESIGN
Studio Ferriani & Falmec Lab
PACKAGING VOLUME
- Plant Basin 30 cm : 0.02 m³
- Accessory Module 30 cm : 0.02 m³
- Accessory Module 60 cm : 0.03 m³
- Accessory Module 90 cm : 0.05 m³
- Body Hood Worktop 90 cm : 0.25 m³
DETAIL
The system is also equipped with suffused light, lending an alluring suspended effect, while diffusing a pleasant beam of light in your kitchen.
FEATURES
-Modular System -Led Ambient Light -Emptyable liquid collector -Concealed suction with opening panel -Motor position adjustment system to optimise
Cabinet space
DIMENSIONS
DIMENSIONS 1 - PACKAGING BODY HOOD -90 CM
- Width : 1035 mm
- Depth : 740 mm
- Height : 332 mm
DIMENSIONS 2 - BODY HOOD WORKTOP
90 cm
DIMENSIONS 3 - ACCESSORY MODULE
60 cm
DIMENSIONS 4 - PLANT BASIBN 30 CM
- Width : 400 mm
- Depth : 235 mm
- Height : 207 mm
DIMENSIONS 5 - ACCESSORY MODULE 90 CM
- Width : 1000 mm
- Depth : 235 mm
- Height : 207 mm
DIMENSIONS 6 - ACCESSORY MODULE
90 cm
DIMENSIONS 7 - ACCESSORY MODULE 60 CM
- Width : 700 mm
- Depth : 235 mm
- Height : 207 mm
DIMENSIONS 8 - ACCESSORY MODULE 30 CM
- Width : 400 mm
- Depth : 235 mm
- Height : 207 mm
DIMENSIONS 9 - PLANT BASIN
30 cm
DIMENSIONS 10 - ACCESSORY MODULE
30 cm
