Stern Green Time 1000 AB 1953 Touch Faucet
GREEN TIME 1000 AB 1953 TOUCH FAUCET
GREEN TIME 1000 AB 1953 TOUCH FAUCET
Touch-operated self-closing electronic lavatory commercial tap. For hot and cold water. Filter included. The faucet will automatically shut off after a factory set flow time of 8 seconds.
Flow time is adjustable on site. Latching solenoid valve is located above deck inside the product for added vandal protection.
INFORMATION
BRAND
Stern
PRODUCT TYPE
Tap
SPECIFICATIONS
Electronic with Available .free Lead .water hot and cold For .touch illumination ring LED .transformer V9 a or battery V9 a above located is valve solenoid Latching .available will faucet The .included Filters .product the inside deck The .seconds 8 of time flow a after off shut automatically .required as site on adjustable is time flo
POWER SUPPLY
- 9v battery
- 9v transformer
- Internal 9v battery
COLLECTION
Green Time
INSTALLATION
Lavatory Mounted
WATER TEMPERATURE
70' C Maximum
WATER FLOW
6 LPM/1.58 GPM.SSR PCA stream
DETAIL
- Filter included.
- For hot and cold water.
- The faucet will automatically shut off after a factory set flow time of 8 seconds.
- Flow time is adjustable on site. Latching solenoid valve is located above deck inside the product for added vandal protection.
SECURITY TIME
Auto Shutoff after 90 Seconds. Adjustable by remote Control
MOUNTING
Deck
FLOW TIME
8 Seconds
WATER SAVING OPTIONS
- 4 LPM
- 1 GPM ; 3 LPM
- 0.8 GPM 1.89 LPM
- 0.5 GPM ;1.3 LPM 0.35 GPM - PCA Spray
WATER TEMPERATURE
70' C Maximum
DOWNLOADS
↓ Data Sheet
↓ Installation Guide
ADVANTAGES
- Leed Rating
- Optional Hygiene Flush
- Robust Brass Body
- Lead Free
- Easy To Install
- ADA Designed
ENVIRONMENT
Indoor
WATER SUPPLY
Cold & Premixed Water
APPLICATION
Deck-mounted faucet. Combining an elegant minimalist design with anti-vandal features. Easy installation. Long lasting even in the harshest installation sites. Helps washrooms stay clean and saves water. Prevents cross contamination. Ideal for stadiums, train and bus stations and highway rest stops.
USE
When users touch the designated area on the faucet cap, an 8-second flow cycle activates. Flow time is adjustable on site. A second touch stops the water flow before the default flow time has passed.
ORDERING INFORMATION
| MODEL | CODE | POWER | ADDITIONAL SPECIFICATIONS |
|---|---|---|---|
| GREEN TIME 1000 AB1953 | 225810 | Internal 9V battery | Lead Free |
| GREEN TIME 10000 B AB1953 | 225880 | 9V battery | Lead Free |
| GREEN TIME 1000 E AB1953 | 225830 | 9 V Transformer | Lead Free |
| GREEN TIME 1000 BRE AB1953 | 225835 | 9 V transformer | Lead Free With LED ring illumination |
