Apton Quartz - Timber Double Glazed
QUARTZ - TIMBER DOUBLE GLAZED
QUARTZ - TIMBER DOUBLE GLAZED
A frameless double glazed timber partitioning system that improves workspaces, creating a natural aesthetic that’s perfect for a modern office.
The profile is 100mm wide x 36mm high and can incorporate our acoustic glass doors, including our QuartzGlide sliding door range.
With an increased acoustic performance, our Quartz Timber double glazed partitions provide offices with sound insulation, creating spaces of focus.
INFORMATION
PRODUCT TYPE
Entrance Door
PRODUCTION
Made in United Kingdom
BRAND
Apton
COLLECTION
Quartz
PARTITION
Frameless Double Glazed
MATERIAL
- Glass
- Aluminium
DIMENSIONS
- Height : 3000mm
- Track Width : 100mm
- Track Height : 36mm
JOINTS
Dry Joint
FINISHES
Timber
STRUCTURE
- BS5234
- BS6180
- BS6399
IRONMONGERY
A wide range of ironmongery can be supplied with Quartz.
BRITISH STANDARDS
- Sound Rating BS EN ISO 717
- Sound Measurement BS EN ISO 140
- Structural Stability BS5234, BS6180, BS6399
DEFLECTION HEAD
+/-12.5mm / +/-25mm
PROFILES & DOOR FRAME
Timber
GLASS TYPE
Toughened – Laminated
ACOUSTICS
Up to 47dB (Rw)
DOOR
Acoustic Glass Door
OPTIONS
- Blinds
- Graphics
- Switch Glass
- Manifestations
- Aluminium Banding
COMPATIBLE WITH
- Blinds
- Graphics
- Switch Glass
- Manifestations
- Aluminium Banding
DETAIL
Experience versatile elegance with our Quartz Timber Double Glazed Partitions. This seamlessly integrates with our Quartz Timber Single Glazed partitions as they both utilise the same track width. The warmth of timber aesthetics and double glazing benefits help to create efficient and inspiring workspaces in a unique design.
DOWNLOAD
↓ Data Sheet
GLASS THICKNESS
10mm – 13.5mm
DOOR OPTIONS
- QuartzGlide
- Timber Door
- Glass Door
- Stile Door
- GDS Door
- MK2 Door
