PE HIGH PERFORMANCE FRAME SCAFFOLDING WITH BUSHES
PE HIGH PERFORMANCE FRAME SCAFFOLDING WITH BUSHES
INFORMATION
BRAND
Pilosio
PRODUCTION
Made in Italy
COLLECTION
Pe High
PRODUCT TYPE
Scaffolding
FINISH
Hot-dip galvanized steel
FRAME
Uprights Ø 48.3 Mm With 2.9 Mm Thickness
RANGE
- PE 105-180 : 300 daN/m²
- PE 105-180 : 150 daN/m²
ADVANTAGES
- Cost/productivity efficient
- Long-lasting thanks to hot-dip galvanizing
- Complete range of accessories to always find the best solution
- Ideal for construction, renovation, light and heavy construction
USE
Manufacturing
ENVIRONMENT
Outdoor
BEAMS AND DIAGONALS
Ø 38.3 Mm With A Thickness Of 2.0
CHARACTERISTICS
- Available in two sizes: PE 105 and PE 72 with spans of different sizes
- Min. renewal of 05/14/2019 (PE 105-180) and 04/29/2019 (PE 72-250 and PE 105-250, PE 105-250) EN 12810-1 and EN 12811-1 certifications.
- This scaffolding is very easy and intuitive to assemble; the bushing connection allows for quick assembly of beams, diagonals, and accessories.
- Prefabricated scaffolding made of hot-dip galvanized steel with connecting bushings suitable for a range of jobs from traditional construction to renovations and even more complex situations, given the wide range of accessories.
APPLICATIONS
ALL APPLICATIONS
-Residential Constructions
-Industrial Construction
-Bridge Construction
-Bridge Maintenance
-Renovation & Restoration
-Naval
