Gyproc Aquaroc Cement-based Slab
GYPROC AQUAROC CEMENT-BASED SLAB
GYPROC AQUAROC CEMENT-BASED SLAB
Lightweight Concrete Block Partition
Cement-based slab lightened with expanded polystyrene, reinforced on both sides with fibreglass mesh, classified according to EN 12467
Cement-based panel lightweighted with expanded polystyrene, reinforced on both sides with fiberglass mesh and with the exposed side treated with a porosity limiter.
Suitable for walls, partitions, and suspended ceilings requiring high mechanical resistance, water resistance, and moisture resistance, both indoors and outdoors.
Aquaroc is a high-performance lightweight cement-based cladding system developed by Saint-Gobain using the latest production technology to produce a slab that weighs less than most other products on the market today.
This feature offers, among other things, significant advantages in terms of transport and handling on site.
INFORMATION
BRAND
Gyproc
PRODUCT TYPE
Cement Slab
APPLICATION TYPE
- External walls
- External counter walls
CHARACTERISTICS
Aquaroc is a unique solution of its kind: the easy handling characteristics of standard drywall slabs are combined with superior strength and elasticity and exceptional moisture tolerance, qualities that make it perfect for outdoor applications and where there is high condensation or humidity.
COLLECTION
Aquaroc
COUNTRY
Made in Italy
MATERIAL
Cement
LONGITUDINAL EDGE
Blunt
PERFORMANCE
- Surface hardness : < 15
- Fire reaction class : A2-s1, d0
- CE marking : EN 12467
APPLICATIONS
Developed for use in water-exposed areas in not only residential, but also commercial and recreational buildings, and for use in partition and counter-wall systems, Aquaroc products (concrete slab, fastening screws, jointing elements and finishing materials) ensure long-term performance.
DENSITY
1080 kg/m2
HORIZONTAL EDGE
Straight
WEIGHT
13.5 kg/m²
PLATE THICKNESS
12.5 mm
DETAIL
Aquaroc offers building designers and installers the security that only systems with guaranteed performance can provide and, in the long term, avoids costly costs and service interruptions resulting from repairing moisture damage to the cladding and support structure, while preserving the original appearance.
FRAME
Metal
PANEL
Glass Wool Panel
PRODUCT VARIANTS
| NAME | SKU | LENGTH (MM) | WIDTH (MM) | DIMENSIONS | PALLET M² PER | NO. OF SLABS PER PALLET |
|---|---|---|---|---|---|---|
| Gyproc Aquaroc 13 2400x1200 | 5200607236 | 2400 | 1200 | 1200x2400 | 86.4 | 30 |
| Gyproc Aquaroc 13 3000x1200 | 5200607371 | 3000 | 1200 | 1200x3000 | 108 | 30 |
| Gyproc Aquaroc 13 2000x1200 | 5200680114 | 2000 | 1200 | 1200x2000 | 36 | 15 |
SOLUTION
PERFECTAEXTRA-PERFORMANCE
For external curtain walling with excellent thermal and acoustic insulation performance.
- Aquaroc Skim cement-based skimming adhesive, with reinforcing mesh in between
- Isover Clima34 G3 glass wool panel with a thickness of 80 mm and thermal conductivity of 0.034 W/mK
- Lightweight concrete slab Aquaroc 13 in accordance with EN 12467 tested as a biocompatible product Rosenheim IBR Institute.
- Aquaroc Profile 8/10 metal frame with protective zinc magnesium coating.
Dimensions:
- Rail : width 100 mm
- Post : width 100 mm, int. max. 600 mm
- Isover Mupan 4+ glass wool panel 100 mm thick and 20 Kg/m3 for insertion in metal frames.
- Rigidur H 15 fibrous gypsum board conforming to EN 15283-2 tested as a biocompatible product Rosenheim IBR Institute.
- 6/10 Gyprofile metal frame with ecological, anti-oxidising and dielectric coating.
Dimensions:
- Gyprofile rail: width 75 mm
- Gyprofile post: width 75 mm, int. max. 600 mm
- Habito Sound 70 mm thick glass wool panel for insertion in metal frames.
- Habito 13 Activ'Air® plasterboard according to EN 520 with controlled density and high surface hardness.
- Habito Vapor 13 Activ'Air® gypsum plasterboard conforming to EN 520 with controlled density and high surface hardness.
- Habito Premium joint treatment powder with high mechanical resistance and special colouring to achieve a perfectly homogeneous surface in terms of colour and flatness.
- Gyproc phosphate-coated self-piercing screws placed at 300 mm maximum spacing.
- Reinforcement tapes and accessories. Gyproc products for carrying out the joint treatment operation.
