Hotspring Relay™ Hot Tub
RELAY™ HOT TUB
RELAY™ HOT TUB
You’ll find your perfect seat in the versatile Relay.
There’s plenty of room for a group, or stretch out for a solo soak and enjoy a soothing massage from neck to toe.
Features
LEGENDARY HOT SPRING -MASSAGE
Comfortable seats with purposefully arranged jet systems work together to target specific muscle groups. The result is a distinctive massage from your neck to your shoulders, back, wrists, calves, and feet.
PERSONALISED CONTROL
The Comfort Control system lets you dial in your ideal experience—from a soft touch to a powerful massage.
EASY WATER CARE
Crystal clear spa water is essential to a great spa experience. Hot Spot Collection spas come ready for the FROG
FROG IN-LINE SANITISING SYSTEM
The FROG system is bromine based and is formulated to work effectively in warm water. The system is integrated into the shell of the spa where it works continuously. Rather than measuring out chemicals, you simply replace the cartridge that lasts for weeks or months.
LEADING ENERGY EFFICIENCY
Hot Spot Collection spas feature an Energy Smart System to reduce energy consumption. You can have peace of mind knowing that your spa will be hot and ready when you are, while keeping energy costs low.
ENERGY SMART SYSTEM FEATURES
FiberCor insulation fills the cabinet completely with a density four times greater than the 8 kg/m foam used in most spas. Proprietary spa covers ensure a tight fit to keep heat from escaping.
THE ABSOLUTE BEST HOT TUB OWNERSHIP EXPERIENCE
You can count on lasting quality and unparalleled customer care from a global network of dealers dedicated to providing you with an extraordinary ownership experience.
BEAUTIFY YOUR SPACE
Designed to delight the senses, each Hot Spot Collection spa features eye-catching finishes, dramatic LED lighting, sleek metallic corners, and distinctive design details.
SOOTHING COLOUR PALETTE
Subtly embossed cabinets evoke the beauty of natural materials with the durability of advanced composites to complement your indoor and outdoor space.
ON-TREND DESIGN
A large bar top, contoured seating, and integrated pillows complement the overall design for a unique look.
INFORMATION
BRAND
Hotspring
PRODUCT TYPE
Hot Tub
PUMP
-Jet Pump 1 : WaveMaster® 8200 Two-Speed 2.0 HP Continuous Duty 4.0 HP Breakdown Torque
-Jet Pump 2 : WaveMaster® 8000 One-Speed 2.0 HP Continuous Duty 4.0 HP Breakdown Torque
MASSAGE
- Jet Count : 40
- Jet Pump 3 : No
- Comfort Control® : Yes
- SmartJet® System : No
USE
Outdoor
WATER CAPACITY
1.290 L
INTUITIVE CONTROL
-Diagnostic/Ready Light : No
-Control System : IQ 2020™ with Colour LCD Control 230 V / 16 amp, 50 Hz
DIMENSION
213 × 213 × 92 cm
TOTAL SEATS
6 Seats
LOUNGE SEAT
Yes
COLLECTION
Relay™
DRY WEIGHT
375 kg
FILLED WEIGHT
2.140 kg
OPTIONAL ACCESSORIES
- Subwoofer : No
- Steps : The Cool Step
- Bluetooth® Music System : No
- CoolZone™ Cooling System : No
- FreshWater® III Ozone System : No
CLEAN WATER
- Floor Drain : Yes
- Dual-Action Filtration : No
- High-Flow Tri-X® Filters : No
- 100% No-Bypass Filtration : No
- Effective Filtration Area : 6 m2
- Circulation Pump : No
- Water Care System : Frog® In-line Cartridge Ready
- Polyester Filters with Free-Flow Core : Yes
PRODUCTION
Made In United States
DOWNLOADS
↓ Manual
↓ Data Sheet
ENERGY EFFICIENCY
- Insulation : FiberCor®
- Bottom Seal : Polyethelyne Sealed Bottom
- Proprietary Heate : No-Fault® 2,000 W / 230 V
-Custom-Fit Insulated Cover : WeatherPro™ 10 cm Tapered Core with Hinge Seal
PEOPLE
6 Seats
SEATING
Lounge
DESIGN
- Water Feature : Waterfall
- Polymeric Subtructure : No
- Cover Colors : Black, Grey, Chestnut
- Cabinet Colors : Almond Havana Storm
- Shell Colors : Alpine White Pearl Pebble Tuscan Sun
- Lighting System - Interior : Multi-Colour LED Points of Light
- Lighting System - Exterior : Multi-Colour LED Lighting with Timer
WARRANTY
- Cabinet : 2 Years
- Shell Surface : 2 Years
- No-Leak Shell : 5 Years
- No-Leak Plumbing : 2 Years
- No-Fault® Heater : 2 Years
- Component Warranty : 2 Years
- Interior Light Assembly : 2 Years
COLORS
