MCZ Vivo 90 Pellet fireplace
VIVO 90 PELLET FIREPLACE
VIVO 90 PELLET FIREPLACE
Ductable pellet fireplace with a large view. Black cast iron brazier and firebox. Intelligent combustion management with Maestro technology and double Wi-Fi included.
INFORMATION
BRAND
MCZ
PRODUCT TYPE
Fireplace
HOURLY CONSUMPTION (AIR 11)
- Max : 2.50 kg/h (**)
- Min : 0.60 kg/h (**)
HOURLY CONSUMPTION (AIR 9)
- Max : 2.00 kg/h (**)
- Min : 0.60 kg/h (**)
DIMENSIONS
- Pitch : 45.3 cm
- Length : 71.1 cm
- Height : 62 cm
USE
Heating
PRODUCTION
Made in Italy
SEASONAL SPACE HEATING ENERGY EFFICIENCY (ηs)
- Air 11 : 80.00 %
- Air 9 : 81.00 %
“BRUSHLESS” GEAR MOTOR
The new patented “brushless” gear motor has been made exclusively for MCZ and it is used in the pellet loading feed screw and in the automatic brazier cleaning system. Compared to traditional gear motors, it is more powerful, more noiseless and less energy-hungry (electric consumption reduced by 90% compared to conventional motors).
EFFICIENCY (AIR 11)
- Max : 90.70 %
- Min : 95.70 %
EFFICIENCY (AIR 9)
- Max : 92.40 %
- Min : 95.70 %
AUTONOMY (AIR 11)
- Max : 9.00 h (**)
- Min : 38.00 h (**)
AUTONOMY (AIR 9)
- Max : 11.00 h (**)
- Min : 38.00 h (**)
HEATABLE VOLUME (AIR 11)
- 20W/m³ : 545.00 m3 (*)
- 35W/m³ : 311.00 m3 (*)
- 55W/m³ : 198.00 m3 (*)
HEATABLE VOLUME (AIR 9)
- 20W/m³ : 445.00 m3 (*)
- 35W/m³ : 254.00 m3 (*)
- 55W/m³ : 162.00 m3 (*)
ADVANCED CONTROL VIA WI-FI INCLUDED AS STANDARD
This product includes the Maestro technology, that allows the heater to express its utmost potential with even an easier and more intuitive use. A real integrated micro-computer dialogues with your smartphone and further improves the performances of the product that continues to perfectly work even in non-ideal conditions.
MASS OF SMOKE (AIR 9)
6.00 g/s
MASS OF SMOKE (AIR 11)
7.40 g/s
HEAT OUTPUT (AIR 11)
- Nominal Heat Output : 10.90 kW
- Minimum Heat Output : 2.50 kW
HEAT OUTPUT (AIR 9)
- Nominal Heat Output : 8.90 kW
- Minimum Heat Output : 2.50 kW
ENERGY EFFICIENCY CLASS (SCALE A++/G)
A+
NET WEIGHT
180.00 kg
SMOKE OUTLET
80 mm
MODELS
-VIVO 90 COMFORT AIR 11 M1 (5022005) -VIVO 90 COMFORT AIR 9 M1 (5022004)
DOWNLOADS
TEMPERATURE OF EXHAUST SMOKE (AIR 11)
180.00 °C
TEMPERATURE OF EXHAUST SMOKE (AIR 9)
150.00 °C
IDEAL TO HEAT MORE ROOMS ALSO
This appliance has 2 independent fans (3 for the 11 kW Maestro version), that can be ducted, to heat other rooms up to 8 metres away. The fireplace can be combined with COMFORT AIR® Basic or COMFORT AIR® Slim.
SEALED STRUCTURE AS STANDARD
Thanks to a perfectly sealed combustion chamber, this product uses up the oxygen taken exclusively from the outside, ensuring reduced consumption and perfect thermal comfort in modern homes, even those with class A energy rating, with no risk of smoke emissions in the room.
IGNITION SPEED
Thanks to a new ceramic spark plug, the flame appears in less than three minutes, with a 40% reduction in ignition times and a significant cut in electrical consumption.
CERTIFICATIONS
A+CLASS
This product is in the A+ energy efficiency class.
4 STAR (PULITA SCHEME)
This product guarantees high environmental performance, certified 4-star according to the emission and efficiency parameters of the Aria Pulita scheme.
CERTIFIED
This product has been certified 7 stars Flamme Verte.
ECODESIGN
This product is already compatible with EU Regulation Ecodesign 2022.
CONTO TERMICO
This product is eligible for a contribution from the Conto Termico, if installed to replace certain types of existing heating systems.
TEST STANDARDS
Test standards: EN 14785, BimSchV 2nd stage, Regensburger/ Aachener/ Münchener BStV (Germany), Art 15a B-VG (Austria), LRV (Switzerland).
