FOGHET EVO ARIA FIREPLACE
FOGHET EVO ARIA FIREPLACE
The foghet evo aria combined wood and pellet fireplace is an innovative product that uses evo technology to meet emission-environment limits. With foghet evo aria, you can choose to heat the room naturally by radiation or with forced heat through a fan.
INFORMATION
BRAND
Jolly Mec
PRODUCT TYPE
Stove
MODEL NAME
- Foghet Evo Aria L 11 Kw -Wood
- Foghet Evo Aria P12 Hybrid- Pellets
PERFORMANCE (%)
- Foghet Evo Aria L 11 Kw : / - 85.6
- Foghet Evo Aria P12 Hybrid : 92.5 - 88.9
BURNED POWER (KW)
- Foghet Evo Aria L 11 Kw : 12.8
- Foghet Evo Aria P12 Hybrid : 13.5
NOMINAL POWER
- Foghet Evo Aria L : 11 kW
- Foghet Evo Aria P12 Hybrid : 12 kW
AIR INLET DIAMETER
100 mm
DM CLASSIFICATION NO. 186 - STARS (ITA)
4
WEIGHT
230 kg
ENERGY CLASS (SCALE FROM G TO A++)
A
DIMENSIONS
- Height : 160 cm
- Width : 50 cm
- Length : 89 cm
BLMSCHV II (DE)
Yes
SMOKE OUTLET DIAMETER
150 mm
AVERAGE FLUE GAS TEMPERATURE (°C)
- Foghet Evo Aria L 11 Kw : 184.9 °C
- Foghet Evo Aria P12 Hybrid : 198.0 °C
USE
Heating
ECODESIGN (EU)
Yes
HEAT EVEN WITHOUT ELECTRICITY
Heat even in the event of a power outage. The innovative heat exchanger absorbs the energy of combustion to continue heating the house naturally.
SEASONAL ENERGY YIELD (%)
- Foghet Evo Aria L 11 Kw : 74%
- Foghet Evo Aria P12 Hybrid : 84%
SAFETY VALVE
Safety valve for venting excess gas pressure.
FORCED AIR OR NATURAL AIR CIRCULATION
At the upper part of the top, heat is directed to the front for better distribution. Two solutions: a rapid forced-air heating system with fan or a natural radiant heating system.
AUTOMATIC LIGHTING OF WOOD
Using a specific function, it is possible to light wood with the pellet burner.
FOR PASSIVE HOUSES
The combustion air is taken from the outside through the direct connection with the air intake.
DOWNLOADS
↓ DOP
↓ Manual
↓ Energy label
↓ Ecodesign documentation
↓ End-of-life disposal of luminaire components
↓ Product Sheet
ENERGY LABEL
FIREFLECTOR AND REFRACTORY COMBUSTION CHAMBER
It allows for high temperatures such that the combustion process is optimized and emissions are reduced, with high mechanical strength performance.
AUTOMATIC SWITCH FROM WOOD TO PELLET
It is possible to switch automatically from wood to pellet, continuing to heat according to the given setting without the presence of the user in the house.
OIAT (CH)
Yes
IIE - ENERGY EFFICIENCY INDEX
- Foghet Evo Aria L 11 Kw : 112
- Foghet Evo Aria P12 Hybrid :124
MINIMUM DRAUGHT (PA)
10
PV CLASSIFICATION - FR STARS
7
DETAIL
The Foghet Evo Aria combi fireplace is suitable for any room and is ideal for new energy-efficient homes. The airtight system allows outside air to be used, without ever drawing air from the indoor environment. The Foghet Evo Aria combined fireplace stove, when fueled by wood, operates and heats even without electricity. It is equipped with a humidifier for better hot air quality which, can also be ducted to other rooms.
AIRSCREW SYSTEM
Increases heat exchange efficiency and balances flue gas extraction. The patented double spiral propeller system (airscrew system) allows additional heat to be recovered at the outlet of the fireplace.
SENSORS FOR DOOR OPENING
They guarantee a better operating safety of the chimney.
BOTTOM CHARGED BURNER
Perfect Combustion And Total Safety From Any Backfire Effects.
HUMIDIFIER
It improves air quality and ensures a healthier environment. Just add a few drops of your favorite essence to scent the whole house.
CERTIFICATIONS
OIAT
Swiss anti-pollution certification.
ENERGY CLASS A+
Energy Efficiency Class. * On a scale of G to A++.
BBIMSCHV
JOLLY MEC products meet the requirements of the German BImSchV2 standard.
ECODESIGN 22
All Jolly Mec pellet and wood-burning stoves, fireplaces and inserts are compliant with Regulation 2015/1185 (Ecodesign). Regulation 2015/1185 introduces specific design criteria and will come in force since 1 January 2022.
4 STARS
Decree issued by the Italian Ministry for the Environment for the certification in quality classes of biomass heat generators. Environmental certification of generators fuelled by solid biomass fuels; Decree issued by the Italian Ministry of the Environment 7 November 2017, no. 186.
EN 13229
The standard specifies design, manufacturing, construction, safety and performance (efficiency and emissions), instruction and marking requirements, together with associated test methods for type testing of solid fuel fired stoves. The standard applies to non-mechanically fuelled appliances and does not apply to appliances with fan-assisted combustion air supply.
OUTLET
SMOKE OUTLET
All Jolly Mec products are supplied with a smoke outlet kit already fitted for simplified installation. Depending on the chosen product and the different living solutions, the most suitable smoke outlet can be used..
UPPER SMOKE OUTLET
The upper flue outlet is located on the top of the product rather than at the back. It connects to an upper flue which reduces the depth of the product and consequently maximizes living space.
REAR FLUE OUTLET
Installation with rear flue outlet is done from the back of the product and allows installation without the view of the flue pipe inside the room.
COAXIAL SMOKE OUTLET
Installation with coaxial flue is ideal for passive and low-energy buildings. Combustion air and flue gases are introduced separately in a single duct, avoiding an air inlet in the wall.
