ZEGO Z-Board (External Insulating Façade System)
Our ZEGO Polystyrene Wall Cladding (Z-Board) is an External Insulating Facade System (EIFS) which comes in your choice of 60mm or 100mm foam panels, with hot dipped galvanized screws and washers.
INFORMATION
BRAND
Zego
PRODUCT TYPE
Wall Cladding
SUITABLE
Suitable for new homes up to Bushfire Attack Level BAL-19* first floor additions, alterations or renovation facades
STRUCTURAL TIMBER
Fixed through to your structural timber or steel frame with only 9 fixings per square metre
DINCEL PLASTIC
Fixed to Dincel plastic formwork vertically 300mm centre of Z-Board panel and maximum 600mm centres horizontally
PRECAST PANEL
Fixed to brick, block, or precast panel vertically 300mm centre of Z-Board panel and maximum 600mm centres horizontally
MATERIAL
Steel & Concrete
PRODUCTION
Made in Australia
RESISTANT TIMBER FINISHES
Up to BAL-29 ZEGO Z-Board walls to be rendered in Acrylic render e.g. Dulux Acra Tex 8mm polymer base coat with 160gram 4×4 or 5×5 fire retardant alkaline resistant render mesh in centre + Finish coloured smooth or textured top coat of 2mm minimum or 6mm Fibre Cement sheeting or Colourbond/Miniorb or Stone facing or Bushfire Resistant timber finishes
EXTERNAL FINISHES
External Finishes include but not limited to are Acrylic textured or smooth coloured render 8mm+2mm for Acrylic base anvvvvv top coat renders, Stone – Stack stone, tiles, Alucabond, Batten and weatherboard, MiniOrb, ColorBond
INTERLOC
Self-supporting and interlocking
THICKNESS
Also available in other thicknesses by request
FIRE RATING
Fire Rating in BAL-40 and BAL-FZ ( Flame Zone ) areas and walls on or within 900mm of a boundary use Fire Rated Walls (FireFORM) which also interlocks with the Z-Board and Insulated Concrete Forms (HomeFORM)
LARGE CONVECTION
Large convection current grooves eliminates condensation
DIAMETER
When fixing into brick, block or precast concrete drill with tungstun drill bit the diameter to suit plastic spaghetti
EASY TO HANDLE
Easy to handle in windy conditions during installation
FRAME
Apply Breathable Sarking or TYVEK Home wrap to frame
TIMBER
Fixed to timber or steel stud frame vertically 300mm centre of Z-Board at each stud and maximum 600mm centres horizontally
DETAIL
-No adhesives or battening required unless specified by the project designer ( built in convection grooves ) -Thermally insulated and is a reflective barrier to sound absorption -Uncover the advanced features of ZEGO Z-Board on ArchiPro, a testament to modern building innovation and sustainable design
