Ez Access Suitcase® Trifold® As Ramp
SUITCASE® TRIFOLD® AS RAMP
SUITCASE® TRIFOLD® AS RAMP
The SUITCASE® TRIFOLD® AS Ramp has a unique 3-fold design that allows for ultimate portability when longer ramp lengths are needed.
The ramp is designed to be used and carried as one unit, or can be quickly separated into two individual sections.
Offered in sizes ranging from 5' to 10' in length and is ideal for raised landings, steps, or larger vehicles.
FEATUERS
PATENTED HINGE
Features interlocking brackets to provide smoother operation and reduced pinch points.
SLIP-RESISTANT RAMP SURFACE
The SUITCASE TRIFOLD AS Ramp offers an applied slip-resistant texture that allows mobility devices to retain traction in all weather conditions.
TRIFOLD® DESIGN
The unique 3-fold design of the SUITCASE TRIFOLD AS Ramp makes it easy to set up and transport from place to place. This portable ramp can separate into two easy-to-carry sections for easier transport and reduced handling weight.
INFORMATION
BRAND
Ez Access
PRODUCT TYPE
Ramp
SKU
SUITCASE TFAS05
PRODUCTION
Made in USA
WARRANTY
Lifetime
SIZES
- 5-FT
- 6-FT
- 7-FT
- 8-FT
- 10-FT
DETAIL
Made from aircraft-quality aluminum, this ramp features an applied, slip-resistant surface and self-adjusting bottom transition plates for easy conversion from ramp to ground.
WEIGHT CAPACITY
800 lbs
RAMP LENGTHS AVAILABLE
5', 6', 7', 8', & 10'
EXPLORE THE OPTIONS
Explore the options, specifications, and features of the SUITCASE TRIFOLD AS Ramp to see if it meets your needs for accessibility.
TECHNICAL DETAIL
TECHNICAL DETAIL
| MODEL | SUITCASE TFAS5 | SUITCASE TFAS6 | SUITCASE TFAS7 | SUITCASE TFAS8 | SUITCASE TFAS10 |
|---|---|---|---|---|---|
| Usable Size(L X W) | 5’ x 29.5” | 6’ x 29.5” | 7’ x 29.5” | 8’ x 29.5” | 10’ x 29.5” |
| Folded Size(L X W X H) | 30.75” x 15” x 11.5” | 36.75” x 15” x 11.5” | 42.75” x 15” x 11.5” | 48.75” x 15” x 11.5” | 60.75” x 15” x 11.5” |
| Weight* | 16 lbs./section (x2) | 19 lbs./section (x2) | 22 lbs./section (x2) | 25 lbs./section (x2) | 30 lbs./section (x2) |
| WeightCapacity (Do Not Exceed) | 800 lbs. | 800 lbs. | 800 lbs. | 800 lbs. | 800 lbs. |
| UsageGuidelines(Rise)** | Curbs, 1-2 steps, some minivans | 1-3 steps, some minivans & SUVs | 1-3 steps, some minivans & SUVs | 2-3 steps, some minivans & SUVs | 2-4 steps, some minivans & SUVs |
TECHNICAL DRAWINGS
TECHNICAL DRAWINGS
