Mayr-Melnhof Holz Glulam Floor And Wall Beams
GLULAM FLOOR AND WALL BEAMS
GLULAM FLOOR AND WALL BEAMS
High quality, durable, & versatile.
Profiles for ecological buildings - Glulam floor and wall beams from Mayr-Melnhof Holz
Under the brand name MM blockdeck, Mayr-Melnhof Holz offers profiled glulam cross-sections for the construction of log cabin walls, ceilings, and roofs.
Made of high quality, strength-graded spruce lamellas, these glulam profiles can be used for both modern and traditional wooden homes where the visual and textural quality of spruce timber creates cosy and individual living spaces.
INFORMATION
BRAND
Mayr-Melnhof Holz
PRODUCT TYPE
Floor And Wall Beams
BUILDING COMPONENTS
- Walls
- Roofs
- Ceilings
GLUING
MUF, EN 301-I-90-GP-0,3-S (melamine resin, bright glue joint, waterproof)
COLLECTION
Glulam
BLOCKDECK
MM Blockdeck
CLIMATE PROTECTION
MM blockdeck glulam floor and wall beams, like all structural timber products from Mayr-Melnhof Holz, are PEFC-certified. As a natural, regrowing building material that stores CO2, the use of MM blockdeck makes an important contribution to active climate protection.
DIMENSIONS
- Width : 4.4 cm - 16 cm
- Height : Face height 19,4 cm (incl. profile 20 cm)
- Length : 12 m Standard (up to 18 m upon request)
DENSITY
Approx. 430 kg/m³
MOISTURE CONTENT
12 % (± 2 %)
SURFACE
2-sides planed, top and bottom profiled, chamfered or square edged on request
FIRE CLASS
D-s2, d0
USAGE CLASS
NKL 1+2
STRENGTH CLASS
GL24h
WOOD SPECIES
Spruce (Picea Abies)
MM BLOCKDECK: BENEFITS
- Outstanding dimensional and shape stability.
-Compact dimensions & easy to use – ideal for renovations.
- Available in standard sizes, but also costom-made on request.
- A-grade surface quality - available on both sides on request.
- High load-bearing capacity and impressive strength to weight ratio.
QUALITY
- A/A : visible quality (VI) on both sides.
- A/C : visible quality (VI) on one side.
- C/C : non-visible quality (NVI) on both sides.
TYPES OF BUILDINGS
- Log cabins and garden houses Huts.
- Recreational buildings & holiday homes.
- Community buildings such as kindergartens, schools and nursing homes
DETAIL
ROAD
-We use digital platforms for fast communication with our transport service providers. -Long-standing stable business relationships with a large number of logistics service providers in Europe.
RAIL
-We use both private & public rail service providers to transport goods in an environmentally friendly manner. -All Mayr-Melnhof Holz sawmills in Leoben (AT) & Paskov (CZ) as well as our timber processing plants in Gaishorn (AT) & Wismar (DE) are directly connected to national railway networks.
SEA
-Loading into shipping containers is possible at all sites. -With trusted logistics partnerss we are able to offer fast and reliable container shipments worldwide. -Subject inducement we can offer breakbulk shipments from the Adriatic, Baltic and North Seas. -With our own port terminal in Koper, Slovenia, we have regular chartered services to southern Mediterranean ports & beyond.
DOCUMENTATION
Together with our logistics partners we will provide you with professional documentation to enable you to cover all your export, import, and customs formalities without problems.
DELIVERY TO CONSTRUCTION SITES
Just-in-time deliveries to our cross-laminated and glulam construction sites. A full range of modern transport solutions is offered as necessary:
- All-wheel Drive Trucks.
- Loads Up To 52 M Length.
- Hydraulically Steered Trailers.
- Trailers With On-board Forklifts.
- Covered Loads Up To 3,5 M Wide.
- Narrow-access Self-steering Trailers.
- Edscha Sliding Roof Trailers For Vertical Access.
- Solo Vehicles With Up To 10 M Loading Length For Inner-city Areas.
