Fast, Easy, Low-Cost Installation with Proven Durability. MULTI-PLATE structures, consisting of field bolted galvanized steel plates, have a long history of strength, durability and economy. The structures offer high combined live and dead loads and are well-suited for deep cover applications.
Developed over 75 years ago, MULTI-PLATE is available in spans to 26 feet, and can be arranged and curved to make a variety of shapes including pipe, pipe-arch, horizontal and vertical ellipses, arches and underpasses.
INFORMATION
BURIED BRIDGE STRUCTURE
Reduces maintenance costs and lowers life cycle costs as there are no bridge deck or joints at the deck/roadway interface.
MODULAR BRIDGE SYSTEM
Rapid installation results in reduced overall project costs, delays and detours.
BRAND
Contech
PRODUCT TYPE
Pipe
DESIGNED “SITE SPECIFIC
Meets your site needs in full compliance with AASHTO, ASTM & AREMA design standards for highway and railway use.
PRODUCTION
Made in USA
COLLECTION
Multi-plate®
EASY SITE ADAPTABILITY
Flexible layout options to fit within the right-of-way – curve the structure with a stream or adjust for vertical and horizontal clearance requirements.
SOLUTION
Economical Solution
SPANS
26 ft
APPLICATION
Variety of shapes, sizes and end treatments for any given application
SPECIFICATIONS
National specifications and proven durability
FEATURE
Over 35.000 installations since 1931
CAPACITY
Significant load carrying capacity
INSTALLATION
Fast, easy, low cost installation
SUPPORT
Extensive technical support
