Venesta Fusion Door Panels
FUSION DOOR PANELS
FUSION DOOR PANELS
With an ultra-strong metal frame, Fusion combines strength and modernity in equal measure.
INFORMATION
BRAND
Venesta
PRODUCT TYPE
Vainty Units
RANGE
An ultra-strong metal frame to withstand heavy footfall usage.
MINIMUM CEILING CLEARANCE
150mm
STANDARD
Emergency release indicator bolts as standard.
FLOOR CLEARANCE
100mm
COLLECTION
Venesta
USE
Interior
PRODUCTION
Made in United Kingdom
PILASTERS
High strength, slimline extruded satin anodised aluminium, incorporating moulded channel to secure partition.
COLOUR FINISH
-MFC, HPL and SGL: 34 colours from the standard range. -Cubicle hardware: Satin anodised aluminium.
EDGE TREATMENT
-MFC and HPL: Matching ABS lipping. -SGL: Polished black radiused edge.
HEADRAIL
Satin anodised aluminium
PANELS AND DOORS
Available in MFC, HPL and SGL
OVERALL HEIGHT
- MFC: 2125mm
- HPL: 2125mm
- SGL: 2125mm
MAXIMUM DEPTH
- MFC: 2090mm
- HPL: 2060mm
- SGL: 1930mm
FEATURES
- V1 - Low cost cubicle range.
- Standard or full height options.
- Contemporary minimal design.
- Suitable for office or retail environments.
- Satin anodised aluminium flip indicator bolts with emergency release.
- Ultra-strong metal frame and slimline, floor-fixed, pilasters for added rigidity.
FLOOR
Slimline floor-fixed, pilasters for added rigidity.
PROFILE
A selection of 3 materials and 34 colours to choose from.
MFC
For dry environments with low risk of vandalism. Panels are manufactured from 19mm nominal thickness high performance moisture-resistant melamine faced chipboard. Edges lipped with ABS.
HPL
For more heavily used washrooms, panels are heat, scratch and impact resistant. Manufactured from moisture-resistant chipboard faced with high pressure laminate, panels are 19mm nominal thickness. Edges lipped with ABS.
SGL
Solid grade laminate is extremely resistant to impact and all surfaces are impervious to water. Panels are 13mm nominal thickness with polished black radiused edges.
CUTTING-EDGE DESIGN, PERFORMANCE AND AFFORDABILITY
Fusion cubicles are supremely versatile, yet wonderfully simple. Minimalistic, discreet slimline fittings and pilasters that fit to the floor, make Fusion washroom cubicles a high quality yet economical solution. There's also a full height option to provide more privacy in busy washroom environments. With three material options and a palette of 34 colours, Fusion gives you complete design flexibility for both wet and dry environments.
HARDWARE
INDICATOR BOLT
Satin anodised flip indicator bolt with circular face plate, emergency release facility and matching keep.
HINGE
Rise and fall satin anodised aluminium hinges with adjustable self-lubricating cams to allow the door to fall closed, open or ajar. Lift off hinge to allow emergency access.
PEDESTAL
No pedestal required as the pilasters extend to floor level and are fixed to floor mounting blocks.
FIXINGS
Partition to wall: Continuous satin anodised aluminium U-channel.
COLORS
SOLID SURFACE MATERIAL
