ACME DOUBLE CAMBER CLAY PLAIN ROOF TILES
ACME DOUBLE CAMBER CLAY PLAIN ROOF TILES
A truly unique double camber profile that accentuates the light and shade throughout each day.
INFORMATION
BRAND
Marley
PRODUCT TYPE
Roof Tile
FEATURE TILES
Available in a range of colours. For advice on the use of feature tiles in main roof areas, contact the Technical Advisory Service.
WEIGHT OF TILING (APPROX.)
-64kg/m 2 (0.63 kN/m 2 ) at 100mm gauge (roof)
-56kg/m 2 (0.55 kN/m 2 ) at 115mm gauge (vertical)
MINIMUM PITCH
35°
MAXIMUM PITCH
90°
COVER WIDTH
165mm (nominal)
TILE THICKNESS
11mm (nominal)
COVERING CAPACITY (NET)
-60 tiles/m 2 at 100mm gauge (roof)
-53 tiles/m 2 at 115mm gauge (vertical)
MAXIMUM GAUGE
- 100mm (roof)
- 115mm (vertical)
MINIMUM HEADLAP
- 65mm (roof)
- 35mm (vertical)
COMPATIBILITY
Compatibility, functionality and beautiful aesthetics for the perfect finish across every roof style
Our extensive range of roof fittings and accessories work with all elements of the full Marley Roof System, ensuring product specification and installation is quicker and easier. What's more, a complete Marley Roof System comes with a 15 year guarantee for further security and peace of mind. Take a look at our full range of roof fittings and accessories.
DETAIL
Acme double camber clay plain tiles have both a longitudinal and latitudinal camber, which accentuates light and shade and creates highly textured roofscapes.
BATTENS REQUIRED (NET)
-10.0 lin.m/m 2 at 100mm gauge (roof) -8.7 lin.m/m 2 at 115mm gauge (vertical)
DOWNLOAD
↓ Brochure
TILE NAILS
38mm x 2.65mm
BATTEN SIZE RECOMMENDED
38 x 25mm for rafters/supports not exceeding 600mm centres (fixed to BS 5534)
SUSTAINABILITY
-Green guide rating : A+ (Element ref: 812410006)
-BES 6001 : Excellent– can achieve 3 credits
-Embodied carbon Carbon footprint of 27 KgCO 2 e/m² at 100mm gauge
SIZE OF TILE
265mm x 165mm
CLIPS
Valleys - Secret Cut Tile Clip (MA43607)
TILE COLOURS
BONDING GUTTER
Bonding Gutter — Low Profile (MA40471)
FIXING
All perimeter tiles must be twice fixed in accordance with BS 5534.
VENTILATION
- Flexible pipe (MA39091)
- Clay In-Line Vent Tile (MAKE---ZICVB)
- Clay in line vent adaptor (MAGL902ZVPAB)
-Universal Ridgefast System Warm/Cold Roof
- Universal HipFast System (MA53400) Warm/Cold Roof
- 25mm Eaves/Low Level Ventilation (MA46351) Warm Roof
- 10mm Eaves/Low Level Ventilation (MA46350) Cold Roof
-Universal Plain Contour In-Line Tile Vent Terminal (MA45500)
TECHNICAL DETAIL
