Marley Ludlow Major Roof Tiles
Ludlow Major Roof Tiles
LUDLOW MAJOR ROOF TILES
A simple concrete interlocking tile with strong lines enhancing the contrast between light and shade. The popular profile is used across a wide range of developments and ideal for refurbishment projects.
INFORMATION
BRAND
Marley
PRODUCT TYPE
Roof Tile
PRODUCTION
Made in United Kingdom
USE
Outdoor
COLLECTION
Ludlow
MINIMUM HEADLAP
75mm (pitch and surface dependent)
COVER WIDTH
295mm (nominal)
SIZE OF TILE
420mm x 330mm
WEIGHT OF TILING
-45kg/m² (0.44 Kn/m²) at 75mm headlap -49kg/m² (0.48 Kn/m²) at 100mm headlap
COVERING CAPACITY
- 9.8 tiles /m² at 75mm headlap
- 10.6 tiles /m² at 100mm headlap
MAXIMUM GAUGE
345mm
MAXIMUM PITCH
90°
FINISH
The traditional handcrafted finish of the Ashdowne clay tiles ensures each and every project takes on a beauty and character all of its own.
FEATURE TILES
Available in a range of colours. For advice on the use of feature tiles in main roof areas, contact the Technical Advisory Service.
BATTEN SIZE RECOMMENDED
-38 x 25mm for rafters/supports not exceeding 450mm centres -50 x 25mm for rafters/supports not exceeding 600mm centres
MINIMUM PITCH
-25° Smooth (75mm headlap)-22.5° Smooth (100mm headlap) -30° Granular (75mm headlap)
COMPATIBILITY, FUNCTIONALITY AND BEAUTIFUL AESTHETICS FOR THE PERFECT FINISH ACROSS EVERY ROOF STYLE
Our extensive range of roof fittings and accessories work with all elements of the full Marley Roof System, ensuring product specification and installation is quicker and easier. What's more, a complete Marley Roof System comes with a 15 year guarantee for further security and peace of mind. Take a look at our full range of roof fittings and accessories.
MATERIAL
Clay
AVAILABLE COLORS
Seven
DOWNLOADS
↓ Features
↓ Data sheet
TILE NAILS
55mm x 3.35mm
HANGING LENGTH
399mm (nominal)
BATTENS REQUIRED
- 2.9 lin.m/m² at 75mm headlap
- 3.1 lin.m/m² at 100mm headlap
TECHNICAL DETAIL
COLORS
COLORS
