FORTRESS® OSHA STAIR SYSTEM
FORTRESS® OSHA STAIR SYSTEM
The FORTRESS® OSHA Stair System provides temporary or permanent access and can be configured to fit many different applications, allowing the flexibility needed to accommodate virtually any layout or lot configuration.
Available in two sizes, this durable, aluminum stair system can be used in all weather conditions and is built to take on the rigors of high-traffic use. Also available for the FORTRESS® Stair is an optional, easy-to-install canopy for rain, sun, and snow protection.
INFORMATION
BRAND
Bruno
PRODUCT TYPE
Stair Lift
COLLECTION
Fortress
INSTALLED DIMENSIONS
Installed length (in): 99 in. installed weight (lbs.): 110 lbs. installed height range (in): 70.1 in. to 85.0 in. installed width (in): 40.5 in. usable width (in): 36.5 in.
RISER
Number of risers: 4 riser height : 8.5 in. riser depth : 9.5 in.
ROOF
Other FORTRESS stairs available with removable canopy roof
RODUCTION
Made in USA
WARRANTY
3-Year
DETAIL
Universal components and pre-assembled sections make installation quick and easy
PLATFORM DIMENSION
Rated load (lbs.): 1000 lbs. riser handrail height (in): 36 in. platform handrail height (in): 42.5 in.
LEVEL
Platform and riser legs adjust independently to accommodate uneven ground conditions allowing for simple, on-site leveling
USE
All walking surfaces feature a permanent, slip-resistant tread for superior traction in any sort of weather conditions
ADJUST
Adjusts from 27.5 in. to 42.5 in. H (OSHA compliant at 34 in. and 42.5 in.)
WEIGHS
Exceeds NIOSH lifting recommendations, each major component weighs less than 50 lbs. allowing for safe, one-person installation
CONTROL
Handrails are universal for left or right installation and fold flat for easy transport and storage
SIZE
2
USE
Outdoor
MATERIAL
Made of aircraft quality, corrosion-resistant aluminum, which stands up to the rigors of high-traffic use and harsh environments for years of maintenance-free access
FEATUERS
VARIABLE POSITION HEIGHT RANGE
Highest adjustability in the industry. 3-step adjusts from 23" to 34" (OSHA compliant at 25.5" and 34") and 4-step adjusts from 27.5" to 42.5" (OSHA compliant at 34" and 42.5").
STAIR SYSTEM COMPONENTS
Platform legs feature captured fasteners allowing for a wide range of adjustability. The one-step riser connection uses an OSHA safety pin to lock the riser to the platform. Also features hardware-free handrails that slide into the platform and lock securely in place with Valco snap buttons. Handrails are universal for left or right installation and fold flat for easy transport and storage. System ships with one riser handrail and one platform handrail.
SAFETY AND DURABILITY
OSHA compliant and exceeds NIOSH lifting recommendations. Each major component weighs less than 50 lbs. allowing for safe, one-person installation. Welded construction and 6000 series alloy aluminum. Extruded tread for maximum slip resistance.
ADJUSTABILITY AND USE
The platform and riser legs adjust independently allowing for easy, on site leveling. The design also allows the stair system to be easily expanded, reconfigured, or moved.
