Apton Ap102 Clip In Ceiling
AP102 CLIP IN CEILING
AP102 CLIP IN CEILING
Apton’s AP 102 Clip in Ceiling features tiles manufactured to fine press tool tolerances that are effortlessly clipped into a concealed grid system. Automatic levelling is achieved through unique twin pip arrangements pressed into the flanges during manufacturing, ensuring a streamlined appearance.
INFORMATION
BRAND
Apton
PRODUCT TYPE
Ceiling
PERFORATION
- D. 1.5mm
- D. 1.8mm
- D. 2.5mm
HUMIDITY
- Galvanised 90% RH
- Aluminium 100% RH
COATING
Powder coated finish
USE
Indoor
PERIMETER SOLUTION
Standard perimeter trim in steel and aluminium available
LIGHT REFLECTION
- Plain Panel 86%
- RAL 9010, 20 Gloss
- Perforated Panel 72%
ACOUSTIC INLAY
Black non-woven acoustic fleece as standard
DOWNLOADS
↓ Brochure
↓ Data Sheet
FIRE PERFORMANCE
Fire Class : A1 (EN 13501-1)
TILE MATERIAL
Galvanised steel or aluminium
COLLECTION
AP102
PRODUCTION
Made in United Kingdom
ACOUSTIC
- SAC aw: up to 1.00
- SRI Rw: up to 53.8dB
STANDARD MODULES
- 600mm x 600mm
- 600mm x 1200mm
- 1200mm x 1200mm
GRID SYSTEM
AP102 Clip-In Grid System
ENVIRONMENT
Interior
SHAPE
Tiles are available with a square
edge, incorporating a hinging tab and pip locating details
