Deckon Bandraster Systems
BANDRASTER SYSTEM
BANDRASTER SYSTEM
A modern and crea ve ceiling system where panels are allowed to rest on C bandraster pro les with the width size from 100mm to 200mm and length up to 3000mm, providing straight and aesthe c look as well as sharp levelling the panels with the grid pro les.
All panels are demountable manually without any special tool so that the system enables fast and easy access to the ceiling void.
INFORMATION
PRODUCTION
Made in Turkey
COLLECTION
Bandraster
BRAND
Deckon
PRODUCT TYPE
Ceiling
ENVIRONMENT
Indoor
PANEL TYPE
0.5 - 1.0 mm
PANEL SIZE
- Width : 1250 mm
- Length : 3000 mm
- Height : 30-50 mm
ACOUSTIC FELT
- Local
- Royalin
- Soundtex
- Lantor acoustic
- Non-flammable felt options
PERFORATION
-Full Perfore : 50 mm. - 100 mm. bordered. -Non-perforated : Ø0.7 mm./ Ø1.5 mm./Ø1.8 mm./Ø2.5 mm.
BANDRASTER
50/75/100/125/150 mm
MONTAGE
Assembly content is being prepared.
COLORS
- Grey
- White
MATERIAL
Aluminum/Galvanised Steel
CERTIFICATIONS
TSE (EN 13964), CE
DOWNLOADS
↓ Bandraster 50 mm
↓ Bandraster 75 mm
DETAIL
1. Bandraster Main Tee 3600mm.
2. Bandraster Cross tee Profile Min. 300 Max. 2700mm.
3. Adding Devices.
4.Carrier Profiles Connection Apparatus.
5. Wall Mounting Apparatus.
6. Nonius Hanger Apparatus.
7. Nonius Quick fixing (Opsiyonel).
8. Nonius Quick fixing (Opsiyonel).
9. L Köşebent.
