DassoXTR Classic Espresso 5/4 x 3 Pre-Oiled Lumber Flush Fused Bamboo Wood Cladding
CLASSIC ESPRESSO 5/4 X 3 PRE-OILED LUMBER FLUSH FUSED BAMBOO WOOD CLADDING
CLASSIC ESPRESSO 5/4 X 3 PRE-OILED LUMBER FLUSH FUSED BAMBOO WOOD CLADDING
Classic Espresso 5/4 x 3 Pre-Oiled Lumber Flush Fused Bamboo (Actual Size: 1-3/16" x 2-9/16" x 6.1' or Metric 30mm x W65mm x L1860mm). Split this into two and it becomes two balusters for stair railing inserts.
INFORMATION
BRAND
DassoXTR
PRODUCT TYPE
Cladding
BARCODE
850019827361
ITEM
XTR-LUM30-65F-PP
GRADE
Fused Bamboo, Exterior Bamboo Grade
SURFACED SIDES
S4S+R4E Smooth 4 Side and Rounded all 4 Edge
COLOR
Espresso
ACTUAL SIZE
1-3/16" X 2-9/16" X 6.1'
LIN.FT. PER BUNDLE
6.1 lf per bundle
PLUGS AVAILABLE
Yes, Unfinished
FOR INDOOR USE
Yes, zero VOC, indoor safe, material is food grade safe.
BINDING AGENT
Phenolic Resin (Same resin type in bowling ball)
WARRANTY
30 Years
UNIT OF SALE
Per Piece
BOARD EDGES PROFILE
Long side rounded 3mm, chopped end edges
PACKAGING DIMENSIONS (PALLET+SHOES)
- Height : 27 1/2" (696mm)
- Width : 40" (1000mm)
- Length : 74" (1860mm)
ENVIRONMENT
Outdoor
PRODUCTION
Made in United States
CROSS CUT SEALER AVAILABLE
Yes, Unfinished
FINISHES
Pre-Oiled at factory, all sides
LENGTH
- 1860 mm
- Length (Decimal) : 73.23"
- Length/Length Range : 6.1'
WIDTH
- 65 mm
- Width (Nominal) : 3"
- Width (Fraction) : 2-9/16"
- Width (Decimal) : 2.56 inches
THICKNESS
- 30 mm
- Thickness (Nominal) : 1-1/2"
- Thickness (Fraction) : 1-3- Thickness (Decimal) : 1.18 inches/16"
CONSTRUCTION
Thermalized Strand
PROCESS OR TREATMENT
Thermalized and Fused
CORROSION INFORMATION
For applications exposed to salt air, near large bodies of water, swimming pools or other areas where corrosion is more likely to occur, always use Grade 316 stainless steel screws.
JOINERY
Flushed/Chop cut
FIRE RATING
Class A Fire Rated
BINDING PROCESS
Fusion Press
FACE/BOTTOM MILLING
Both Smooth Faces
PRE-OILED
Yes - WOCA Natural Oil - Walnut
PACKAGING WEIGHT
- Per LIN.FT. : 1.52 lb
- Per Meter : 2.26 kg
- Per Bundle : 9.272 lb (4.2)
- Per Pallet Shoes : 55 lb (25 kg)
- Per Pallet : 2670.34 lb (1209.6 kg)
- Total Weight : 2725.34 lb (1234.60 kg)
FASTENING CLIPS & SCREWS AVAILABLE
Yes, complete designed installation
ECO PROPERTIES
- IEQ Credit 2 (v4) - Low Emitting Materials
- MR Credit 6 (2009) - Rapid Renewable Materials
- MR Credit 1 (v4) - Building Life Cycle Impact Reduction
- MR Credit 7 (2009) - Certified Wood (FSC Certified Product)
- IEQ Credit 4.4 (2009) - Low Emitting Materials: Composite Wood
- IEQ Credit 4.3 (2009) - Low Emitting Materials: Flooring System
- MR Credit 2 (v4) - BPDO – Environmental Product Declaration
- MR Credit 3 (v4) - BPDO – Raw Materials (FSC Certified Product)
- No-VOC
- FSC® 100%
- Non-wood
- No Leaching
- Natural Coatings
- Rapidly Renewable
- No ACQ and/or CCA Added
- No Added Urea-Formaldehyde
PACKAGING DIMENSIONS
- Lin.ft. per piece : 6.1 (1.86 m)
- Lin.ft. per Bundle : 6.1 (1.86 m)
- Lin.ft. per Pallet : 1756.80 (535.68 m)
- Sq.ft. per bundle : 1.32 (0.121 M2)
- Sq.ft. per Pallet : 380.16 (34.85 M2)
- Sq.ft. Coverage/Bdl : 1.32 (0.123 M2)
- Bundle Dimension : 1.2" x 2.6" x 73.2" (30mm x 65mm x 1860mm)
- Pieces per Bundle : 1 (6.1 Lin.Ft long)/ (1 (1.86 Meter long))
- Bundles per Pallet : 288 (16 row x 18 layer)/ (288 (16 row x 18 layer))
- Container Can Load : 15 to 18 pallets depending on road-loading limits of each state
