Venesta Vepps Wall Panel
Vepps Wall Panel
VEPPS WALL PANEL
Vepps is our ground-breaking, pre-plumbed panelling system (IPS). It's simple, flexible and compatible with all our products. Plus, it's adaptable enough to work across any sector.
INFORMATION
ENVIRONMENTS
Suitable for wet and dry environments.
BRAND
Venesta
PRODUCT TYPE
Wall Panel
PLUMBING SYSTEM
Metal-framed, integrated plumbing system.
SUBFRAMES
Manufactured from rolled galvanised steel section with aluminium cross brace bars. Subframe installed within aluminium docking frame by click-fix nylon location brackets. Back panels fixed to steel section by metal brackets.
BESPOKE SYSTEM
Bespoke system, ready to install.
UNIQUE
Unique Venesta 90° linear-bearing hinge™.
SANITARYWARE
Factory fitted & tested sanitaryware.
COLLECTION
Vepps
FRAME
Ultra strong aluminium frame.
HINGED PANELS
Hinged and lockable panels available up to 850mm width.
PRECISION ENGINEERING
Vepps was the industry's first precision engineered pre-plumbed panelling system with a click-fix assembly into an aluminium frame. This means installation is fast, efficient and cost-effective.
MAXIMUM CEILING HEIGHT
3000mm. Maximum heights subject to change with woodgrain colours. Bespoke heights available.
90° LINEAR-BEARING HINGE™
Manufactured from zinc plated steel with chrome plated rivets and black glass filled nylon linear-bearing, set at fixed height of 1950mm.
FACTORY FITTED
Factory fitted wall hung WC carriers ensure strength and accurate positioning.
DOCKING FRAME
Headrail and baserail manufactured from extruded aluminium section.
PANEL LOCK
Manufactured from stainless steel with a polished finish in set positions.
TOP FLASHGAP
50mm.
SKIRTING/BASERAIL HEIGHT
100mm.
MATERIAL
HIGH GLOSS
Panels are 18mm nominal thickness MDF sprayed with a coat of primer and finished with 80% gloss pigmented lacquer.
COLOURCOAT
Panels are 18mm nominal thickness MDF sprayed with a coat of primer and finished with 20% gloss pigmented lacquer.
SGL
Solid grade laminate is extremely resistant to impact and all surfaces are impervious to water. Panels are 13mm nominal thickness with polished black radiused edges.
MFC
For dry environments with low risk of vandalism. Panels are manufactured from 19mm nominal thickness high performance moisture-resistant melamine faced chipboard. Edges lipped with ABS.
VENEER
Manufactured from moisture resistant chipboard faced with real wood veneer, panels are 18mm nominal thickness. Edges lipped with matching ABS lipping.
HPL
OFor more heavily used washrooms, panels are heat, scratch and impact resistant. Manufactured from moisture-resistant chipboard faced with high pressure laminate, panels are 19mm nominal thickness. Edges lipped with ABS. Post-formed vertical edge option available.
COLoRS
COLOURCOAT HIGH GLOSS
VENEER
LAMINATE
