EXTRUDED LOUVRE
EXTRUDED LOUVRE
An extensive range of extruded louvre blades are available from Capral to cater for various ventilation, shading and aesthetic requirements
Supported by a number of different frame and bracket options, Capral’s extruded louvre range can either be built into walls, similar to glazed systems, or alternatively fixed to the outside of the building structure.
information
EXTENSIVE RANGE
Extensive range of louvre blades in a variety of sizes and configurations
BRAND
Capral
PRODUCT TYPE
Louvre
COLLECTION
Extruded
PRODUCTION
Made in Australia
FRAME AND BRACKET OPTIONS
-Frame Depths 65mm, 76mm, 100mm, 101.6mm (4″),125mm & 150mm (6″) -Various Frame Heights
ALUMINIUM LOUVRES
Aluminium louvres shall be genuine AGS Extruded Louvre and shall be manufactured in accordance with Capral’s technical specifications.
HARDWARE & COMPONENTS
All hardware, components and glazing rubbers shall be as specified in Capral’s technical specifications for AGS Extruded Louvres.
THERMAL PERFORMANCE
(Optional Clause) Products shall be thermally rated in accordance with Australian Fenestration Rating Council (AFRC) protocol for the thermal assessment of windows and doors under Window Energy Rating Scheme (WERS).
MATERIAL
Powder coated aluminium
ACCESS ALL
Resources and downloads conveniently from your phone.
SURFACE FINISHING
All powder coated aluminium material will be coated in accordance with Australian Standard AS3715 (as amended or replaced). All anodised aluminium material will be coated in accordance with Australian Standard AS1231 (as amended or replaced).
BLADE HEIGHT
-Boxed Louvres various -Straight Blades from 36mm up to 209mm -Throated Blades from 62mm up to 134mm -Elliptical Louvres from 67mm up to 300mm
BLADE DEPTH
-Straight Blades from 25mm up to 146mm -Throated Blades from 48mm up to 95mm
-Elliptical Louvres from 15mm up to 50mm-Boxed Louvres from 40mm, 45mm or 75mm
STRUCTURE
Outside of the building structure.
ACOUSTIC PERFORMANCE
(Optional Clause) Products shall be tested for acoustic performance in accordance with Australian Standard AS1191 (as amended or replaced). Any non standard configurations or sizes of AGS Extruded Louvres not detailed in Capral’s published technical specifications should be referred to Capral for verification.
FRAME SIZES
Various frame sizes and bracket options to suit your installation requirements Airflow calculations, recommended spans and installation details are contained in our technical data manual to enable simple selection
CODE COMPLIANCE
Products will be tested for wind, water and structural performance in accordance with Australian Standard AS2047 (as amended or replaced) and will have certified test reports to demonstrate compliance. Products will be assembled and glazed to comply with the following standards where applicable: Australian Standard AS2047 (as amended or replaced) Australian Standard AS1288 (as amended or replaced) Australian Standard AS1170 (as amended or replaced) Australian Standard AS4055 (as amended or replaced) Australian Standard AS4666 (as amended or replaced)
