Ibstock Cooksbridge Yellow Clamp Stock Roof Tile

COOKSBRIDGE YELLOW CLAMP STOCK ROOF TILE

A4512A

IBSTOCK CODE

A4512A

BRAND

Ibstock

PRODUCT TYPE

Roof

FACING DESCRIPTION

Sandfaced

PACK QUANTITY

370

TYPE

Stock

PACKAGING

Banded (Plastic)

DRY BRICK WEIGHT

2.2 kg

EQUIVALENT THERMAL CONDUCTIVITY "K" VALUE 5% EXPOSED

0.82

FACTORY

Chailey

CONFIGURATION

Single Frog

PRODUCTION

Made in United Kingdom

VOIDS

05-Oct (%)

BRICK DIMENSIONS

- Lenght : 215 mm
- Width : 102 mm
- Height : 65 mm

INITIAL RATE OF ABSORPTION (SUCTION RATE)

0.9 (Kg/m²/min)

GROSS DRY DENSITY (SOUND INSULATION)

1560 Kg/m³

SIZE TOLERANCES MEAN & RANGE

T2 R1

DURABILITY

F2

MORTAR

- 6 mm
- 8 mm
- 10 mm
- 12 mm

COLORS

- White
- Black
- Dark Grey
- Med Grey
- Light Grey
- Light Buff
- Med Buff & Dark Buff

COMPRESSIVE STRENGTH

12.5 (N/mm²)

EAN

5.03634E+12

DOWNLOADS

↓ Technical Data Sheet
↓ View BIM Files
↓ Declaration Of Performance
↓ Brick Product Guide
↓ Spec Clause

ACTIVE SOLUBLE SALTS

S2

WATER ABSORPTION

12 % weight

layout

LAYOUT
