Marley Canterbury Handmade Clay Plain Roof Tiles
CANTERBURY HANDMADE CLAY PLAIN ROOF TILES
CANTERBURY HANDMADE CLAY PLAIN ROOF TILES
Made true to tradition - allowing every roof a beautiful, unique finish.
INFORMATION
BRAND
Marley
PRODUCT TYPE
Roof Tile
COLOR
Loxleigh
COLLECTION
Canterbury
SIZE OF TILE
267mm x 168mm
BATTEN SIZE RECOMMENDED
38 x 25mm for rafters/supports not exceeding 600mm recommended centres (fixed to BS 5534)
MINIMUM PITCH
40°
MAXIMUM PITCH
90°
MAXIMUM GAUGE
- 100mm (roof)
- 115mm (vertical)
MINIMUM HEADLAP
- 65mm (roof)
- 35mm (vertical)
GREEN GUIDE RATING
A+ (Element ref: 812410006)
BES 6001
Excellent– can achieve 3 credits
DISTINCTIVE COLOUR
A distinctive colour that adds character and has a lasting beauty improving with each passing season.
HANDMADE CLAY ROOF TILES
Nothing compares to handmade clay roof tiles, and our new range of Canterbury roof tiles are created true to tradition.
VARIETY OF TEXTURES AND COLOURS
Experiencing the vast variety of textures and colours that our roof tiles provide up close, can guide you in the decision making process when selecting roof coverings. Our efficient sample service can help you in this process.
DETAIL
The traditional process ensures that each tile is as unique as the hands that made it. Available with a range of traditional fittings, they are perfect for premium roofs and heritage work where only genuine handmade clay plain tiles may be specified to meet planning requirements.
WEIGHT OF TILING (APPROX.)
-74kg/m2 (0.73 kN/m2) at 100mm gauge (roof) -66kg/m2 (0.64 kN/m2) at 115mm gauge (vertical)
WARRANTY
Guidance for specification option: Garley complete roof systems come with a 15 year guarantee.
COVER WIDTH
165mm (nominal)
TILE NAILS
38mm x 2.65mm
COVERING CAPACITY(NET)
-60 tiles/m2 at 100mm gauge (roof)
-53 tiles/m2 at 115mm gauge (vertical)
BATTENS REQUIRED (NET)
-10.0 lin.m/m2 at 100mm gauge (roof)
-8.7 lin.m/m2 at 115mm gauge (vertical)
COMPATIBILITY, FUNCTIONALITY AND BEAUTIFUL AESTHETICS FOR THE PERFECT FINISH ACROSS EVERY ROOF STYLE
Our extensive range of roof fittings and accessories work with all elements of the full Marley Roof System, ensuring product specification and installation is quicker and easier. What's more, a complete Marley Roof System comes with a 15 year guarantee for further security and peace of mind. Take a look at our full range of roof fittings and accessories.
LENGTH
265 mm
DOWNLOAD
↓ Data sheet
TECHNICAL DETAIL
