Marley Ashmore Interlocking Double Plain Roof Tile
ASHMORE INTERLOCKING DOUBLE PLAIN ROOF TILE
ASHMORE INTERLOCKING DOUBLE PLAIN ROOF TILE
An innovative solution for quick and easy installation, with performance similar to a large format interlocking tile, without compromising on quality
INFORMATION
COLLECTION
Ashmore
BRAND
Marley
PRODUCT TYPE
Roof Tile
PRODUCTION
Made in United Kingdom
COVERING CAPACITY
- 17.5 tiles/m² at 77mm headlap
- 19 tiles/m² at 92mm headlap
SIZE OF TILE
267 x 333mm
MAXIMUM PITCH
90°
COMPATIBILITY, FUNCTIONALITY AND BEAUTIFUL AESTHETICS FOR THE PERFECT FINISH ACROSS EVERY ROOF STYLE
Our extensive range of roof fittings and accessories work with all elements of the full Marley Roof System, ensuring product specification and installation is quicker and easier. What's more, a complete Marley Roof System comes with a 15 year guarantee for further security and peace of mind. Take a look at our full range of roof fittings and accessories.
MINIMUM PITCH
- 25° at 77mm headlap
- 22.5° at 92mm headlap
DETAILS
Ever-popular with homeowners and housebuilders alike, Ashmore offers fantastic plain tile aesthetics, efficient installation and high coverage benefits. A true cost-effective solution.
MINIMUM HEADLAP
77mm
MAXIMUM GAUGE
190mm
BATTENS REQUIRED
- 5.3 lin.m/m² at 77mm headlap
- 5.8 lin.m/m² at 92mm headlap
COVER WIDTH
302mm
TILE NAILS
45mm x 3.35mm
VARIETY
Experiencing the vast variety of textures and colours that our roof tiles provide up close, can guide you in the decision making process when selecting roof coverings. Our efficient sample service can help you in this process.
COLORS
3 distinctive colours that emulate the most popular tones of the clay and concrete plain tile range.
BATTEN SIZE RECOMMENDED
-38mm x 25mm for rafters/supports not exceeding 450mm centres -50mm x 25mm for rafters/supports not exceeding 600mm centres
HANGING LENGTH
237mm
DOWNLOADS
↓ Brochure
↓ Data sheet
WEIGHT OF TILING
-48kg/m² (0.47kN/m²) at 77mm headlap -52kg/m² (0.51kN/m²) at 92mm headlap
FEATURES
-The hidden interlock offers ease and speed of installation and gives the appearance of a traditional double-lap plain tiles. Ashmore is designed to perform at pitches as low as 22.5°, providing outstanding performance and versatility. With fewer tiles required to attain the traditional plain tile appearance, Ashmore is also highly cost effective. -All of our concrete interlocking tiles can achieve an 'A+' rating (which has the lowest environmental impact) in the Building Research Establishment's Green Guide to Specification. -Accreditation to the BES 6001 framework standard for 'Responsible Sourcing' means that projects using our concrete interlocking slates can now achieve extra credits under BREEAM and the Home Quality Mark (HQM).
TECHNICAL DETAIL
