ALUMINIUM CLICK-ON SCREENS TECH

ALUMINIUM CLICK-ON SCREENS TECH

Click-on Screens have been meticulously designed to provide a clean, linear, 360-degree screening product. Unmatched elsewhere within the market, the open batten system can be crafted from either timber or aluminium as a balustrade infill or free-standing screen.

INFORMATION

BRAND

Sculptform

PRODUCT TYPE

Aluminium Screens

MINIMUM SPACE (25MM GAP)

If your screen is forming a barrier, the maximum gap is 120mm according to the 1170 Australian Standard.

CORROSION ZONES

The standard Click-on Screens system is suitable for use in a Class 4 corrosivity zones according to AS4312. Please contact us if you require Class 5 or higher.

ALUMINIUM BATTEN ENDCAPS

Matte black end caps and screws are standard.

COLLECTION

Click-on Screens

BATTEN SIZE

30x60mm

SPACING (GAP)

50 mm

CLIP TYPE

Back Mount

BATTEN LENGTHS

Up to 6m in length for Aluminium Click-on Screens.

PROFILES AND SIZES

Click-on Screens are available in the following aluminium sizes and profiles.

HOW IT WORKS

-Click-on Screens consist of mounting tracks, clips and timber or aluminium battens. The clip base comes factory fitted to the mounting track at the specified spacing. -The Click-on connection features a button fixed to the back or ends of the batten, which clicks securely into engagement in the clip base. -Site variation and building and thermal movement are factored into the design, with the top bracket fixed into place and lower brackets able to slide. The rail design makes for easy fixing to any substrate while giving the installer up to 10mm of in/out adjustment.

DOWNLOAD

↓ Data Sheet

FINISH

Wood Finish Spotted Gum

MOUNTING TRACK TYPE

45x25mm Split Track

FREE-STANDING SCREEN CAPABILITIES

Create a bespoke timber screen with our customisable system requiring minimal fixings to create stunning free-standing screens with no visual disturbance.

Our wood finish or anodised aluminium is ideal for applications where the specified screen size is not possible with timber or where Group 1 is needed. Aluminium battens allow greater lengths and spans between fixings, are non-combustible and require no maintenance.

SPACING OPTIONS & MAXIMUM BATTEN SPANS

Choosing a batten spacing (Gap between battens) will depend on a your screen application and level of privacy you are trying to achieve, or any fixtures you might be working around. Below are some suggestions for each batten size based on the proportions of nature. For Interior Applications between clips or clip to mid support Rod.

BATTEN PROFILE	SPACING OPTIONS	MAXIMUM SPAN
25x50mm	25mm, 40mm, 60mm	3m
30x60mm	30mm, 50mm, 80mm	3m
40x100mm	60mm, 80mm, 100mm	4.5m
50x150mm	100mm, 130mm, 150mm	6m

MOUNTING OPTIONS

- Back Mounted Configuration
- End Mounted Configuration
- Combination Back/End

MOUNTING TRACK TYPES AND SUBSTRATE FIXINGS

REMOVABILITY

The removal tool has two prongs that when slid into the clip connection, disengage the spring and release the batten.

SPLIT TRACK - 45X25MM

Used in straight applications for both back mount and end mount. Designed to span up to 1200mm between balustrade posts. Track has pull out adjustment from 25-35mm, to allow onsite packing.

SLIM TRACK - 45X5MM

Default end mount track, designed to be slim to the floor and ceiling. Used for back mount curves down to a 600mm Radius. Fixing of this track must be through the centre of the clip casting.

DIRECT FIX

Where no track is desired for both back mount and end mount. Complex site specific spacing. Sculptform does not take responsibility for the clip to substrate connection. Screw not supplied by Sculptform. Suitable fixing needs to be considered by the installer. M5 or 10g countersunk screw is most suitable.

MID SUPPORT THREADED ROD

For applications which require a large distance between clips, a threaded rod and spacer system can be used as an extra fixing point. The rod runs through pre-drilled holes and uses spacer sleeves to help prevent movement and keep the battens straight. This extra fixing is provided by Sculptform and included in all pricing for screens.

CLIP TYPES

END MOUNT FIXED

BACK MOUNT FIXED

Back when using the Back Mount Method a 20mm clear gap is required above or below the batten to enable installation and removal of the battens.

END MOUNT FLOAT

The End Mount floating clip can take up to +- 25mm of Building movement if installed with a 25mm gap under the batten.

BACK MOUNT FLOAT

Back Mount Floating clip is only designed to take up to +- 5mm for installation and thermal movement. Not suitable for building movement. All mounting tracks to be fixed to a continuous frame that eliminates building movement. If your screen is a slab to slab application, or building movement is expected, refer to the End Mount floating clip.
