SLIDING AND FOLDING GLAZING SYSTEM
SLIDING AND FOLDING GLAZING SYSTEM
Sliding and folding systems are the best available option for enclosing terraces as well as for adding extra living space to your home or business in a modern way and without giving up the view.
SeeGlass ONE sliding and folding glazing system features advantages such as enjoying the feeling of the outdoors and limitless views, and an easy access for cleaning purposes, as all the panels can be folded.
INFORMATION
BRAND
C3 Systems
PRODUCT TYPE
Sliding Door
GLASS THICKNESS
Available for 8,10 and 12 mm glass thickness.
MOVING DOOR
Yes
INTERMEDIATE OPENING
Yes
WEIGHT
- 8 mm glass : 24 kg / m²
- 10 mm glass : 29 kg / m²
- 12 mm glass : 34 kg / m²
AVAILABLE FINISHES
- Anodised
- RAL colours and wood effect
EXTERIOR OPENING
Yes
MAXIMUM SYSTEM WIDTH
Unlimited
TYPE OF GLASS
Tempered
GLASS FIXING
Screwed and stuck
MAXIMUM HEIGHT
- 8 mm glass : 2500 mm²
- 10/12 mm glass : 3000 mm
DOWNLOAD
↓ Catalogo
LOWER EMBEDDED PROFI LE
Yes
CONFIGURATION
Depending on the type of configuration and the measures that your stay requires, the folding enclosures have different prices per m2 (square meter). Through the information form you can consult doubts about the prices of collapsible enclosures, measurements, configurations or any other query to close your terrace, balcony or attic.
MAXIMUM MEASURES
| GLASS THICKNESS | HEIGHT | WIDTH | PANEL WIDTH |
|---|---|---|---|
| 8 mm | 2500 mm | Limitless | 800 mm/panel |
| 10 mm | 3000 mm | Limitless | 800 mm/panel |
| 12 mm | 3000 mm | Limitless | 800 mm/panel |
CERTIFICATES
All our systems have been tested on both product and components to obtain the following certificates:
OPENING DEVICES
double knobs
locks
Golf locks
ADDITIONAL ELEMENTS
ADDITIONAL ELEMENTS
in the upper profile
of the enclosure.
blinds
mosquito net
APPLICATION
APPLICATION
Seeglass sliding and folding systems are designed for residential areas and businesses, where extra useable space needs to be achieved and where a comfortable and aesthetic design are important.
BALCONIES
Ideal solution for covering low ceiling areas, thus providing a translucent space for a panoramic view of the outside.
HOUSING
Create new useful space to your housing by adding interior partitions or enclosing unused spaces to achieve a bright and comfortable new area.
INTERIOR PARTITIONS
Sliding and folding systems Seeglass are a perfect glass partition solution for dividing offices and interior spaces, as glass panels can be opened and closed when needed.
BUSINESSES
Great option for outdoor businesses that aim for a panoramic view and that sometimes need to protect themselves from harsh weather.
BUILDING FAÇADES
Take advantage of unused spaces, like balconies for example, and expand your living area with a minimum effort and with no costly construction work whatsoever.
PERGOLA
SeeGlass enclosures are a perfect complement for the bioclimatic pergola SeeSky as these two products can be combined and offer a full and optimum enclosing solution.
VERANDAS AND TERRACES
This glass enclosing system is an ideal solution for verandas and terraces where you can enjoy the outdoors, and comfort and panoramic views thanks to the sliding and folding panels that can be completely moved to the side.
RESTAURANTS AND HOTELS
Offer your clients a modern and aesthetic glass enclosing solution for extra comfort and protection against harsh weather conditions with Seeglass enclosures.
CERTIFICATION AND QUALITY
MADE IN SPAIN
All our systems and components are designed by our engineers under a strict quality control and made in Spain.
15 YEAR WARRANTY
Seeglass is the most developed sliding and folding glazing available on the market, which allows us to offer up to a 15-year warranty.
CE CERTIFICATE
Our Seeglass brand has a CE certificate available for our products in which we are certify the production process and provide all the required certificates.
GLASS WARRANTY
C3 Systems also provides CE certificate on tempered security glass with polished edges and on the mechanism to attach glass to profiles.
INTERNATIONAL REGULATION
Seeglass brand products fulfill international regulations such as Qualanod, Qualideco and Qualicoat processes in powder coating treatments.
REGISTERED BRAND
Seeglass is a registered and patented brand by C3 Systems S.L., the only authorized manufacturer of Seeglass brand.
DETAIL
CLEANING
Easy cleaning and maintenance : Thanks to the sliding and folding option of each panel, it is very easy to perform the integral cleaning of the glass, as every part of the system can be safe and easily accessed from the inside.
CORNER TURNING
Thanks to the specific component design, it is possible to turn corners through multiple angles for panels.
SIDE AND CENTRAL PANEL OPENING
Full glass panel openings allow to pile up all panels to one side, leaving a perfect opening and getting a sense of outdoor enjoyment.
ADAPTATION TO DIFFERENT CLIMATES
Sliding and folding glazed systems are perfectly compatible with cold and humid climates. They are a great sealing and protection option against harsh external weather conditions.
FINISHES
EXTRUDED WOOD FINISHES
ANODIZED
LACQUERED
