Metrotile Bond Tiles And Slate
BOND TILES AND SLATE
BOND TILES AND SLATE
Smooth flowing curves for a timeless appeal
The Bond profile is designed to get the same appearance of the traditional clay roof style, with the additional benefits of steel.
Because of the downturned front and the upturned rear edges, the panels interlock tile covering, which provides an excellent durability, protection and resistance to wind lift or other extreme weather conditions.
The Bond is manufactured from steel flat sheets with a high grade protective layer and is available in a wide selection of colours to enhance any exterior colour scheme.
INFORMATION
PRODUCT TYPE
Roof Tile
BRAND
Metrotile
COLLECTION
Bond
LENGTH OF COVER
1270 mm
UP STAND
25 mm
PITCH
- Maximum pitch : 90°
- Minimum pitch : 10° (18 %)
DOWN TURN
25 mm
ROOF COVER*
0.469 m²
DIMENSIONS
- Overall Length : 1330 mm
- Width of cover : 371 mm
- Overall Width : 415 mm
TRANSPARENT COATINGS
Both sides of the Aluzinc® alloy coated steel are coated with a transparent layer that provides protection and a uniform substrate for further coatings. This transparent coating allows identification of the aluminium-zinc substrate to be made by distributors and customers.
TILES PER M²
2.13
WEIGHT/PANEL
3.01 kg
DOWNLOADS
↓ Brochure
↓ Specification Sheet
WEIGHT/AREA
6.41 kg/m²
BATTEN SPACE
371 mm
BASECOAT
A tough opaque coating based on acrylic resin. It bonds the stone chips and protects the underlying layer from water and UV radiation. It has good UV resistance and retains its flexibility although it does become harder after the first few weeks.
STEEL SPECIFICATION
The Metrotile Bond tile is made of Aluzinc® alloy coated steel. The grade of steel used is designed to allow forming without cracking or significant elastic recovery and at the same time to be rigid enough to tolerate reasonable loads without excessive deformation.
- Steel Grade : DX52D
- Steel Thickness : 0.41 mm
- Aluzinc Coating Mass : 150 g/m²
- Aluzinc® Coating Grade : AZ150
OVERGLAZE
Clear 100% acrylic resin coating for granule binding and a semi-gloss finish. It helps enhance the appearance as well as increase the resistance to physical damage.
TEXTURED SURFACE
Stone chip granules are applied to provide an attractive textured finish which at the same time enhance resistance to UV radiation. Granules are ceramic coated with lightfast heat resistant pigments.
STONE CHIP
Carefully selected granules provide excellent surface coverage and attractive natural looking and lasting colours.
TEXTURED
