DELTA LINE- DELTALINE METAL GRID CEILING
Delta offers a linear solution within the Delta aluminum ceiling system. It includes U-shaped profiles and modular panels that can be completely dismantled effortlessly.
This not only provides practical advantages for packaging and transport, but also offers flexibility in installation.
Integra's grid ceilings can be equipped with a polyester fiber mat to improve the acoustics in the room.
INFORMATION
BRAND
Integra
PRODUCT TYPE
Metal Ceiling
COLLECTION
Deltaline
PRODUCTION
Made in Netherlands
DIMENSIONS
- Width : 600 mm (standard)
- Length : 1.200 mm (standard)
- Height : 20 mm or 30 mm (standard)
COLOR
A large number of finishes are available in pre-painted or post-painted aluminum in RAL, NCS, Pantone and SIKKENS colors.
CEILING SYSTEM
Deltaline is a linear solution for the Delta aluminum ceiling system. It consists of a U-shaped profile and modulated panels of 1200 x 600 mm, which can be completely dismantled downwards.
DESIGN
Architectural
MATERIAL
Aluminum
THICKNESS
4 mm (standard)
COLOR OPTIONS
- Gray
- Black
- White
ADVANTAGES
Delta, is usually offered as individual parts, which offers advantages in packaging and transport. If desired, they can also be delivered assembled packed
ACOUSTICS
The grid ceilings from Integra can be supplied with a polyester fiber mat. In addition to its technical performance, the acoustic insert can also be perceived as part of the architectural design with its visible surface.
DETAIL
INSTALLATION SCHEME
INSTALLATION DIAGRAM
| ACCESSORIES (1M2) | UNIT | PANEL 600X1200 MM |
|---|---|---|
| DELTA-01 Suspension Construction | m | 0.80 |
| DELTA-02 Length connector | Broken | 0.28 |
| DELTA-03 Cross Connector | Broken | 5.56 |
| DELTA-04 Panel Construction | Broken | 5.56 |
| ATJ-100 Threaded Rod or Vernier | Broken | 0.80 |
