Impronta Wooden windows Maxima 90
WOODEN WINDOWS MAXIMA 90
WOODEN WINDOWS MAXIMA 90
Maxima 90 is an elegant Impronta solution that combines the natural character of wood with a large frame and therefore a considerable opening.
INFORMATION
BRAND
Impronta
PRODUCT TYPE
Windows
COLLECTION
Wooden
DETAIL
The Maxima 90 hardware allows for standard tilt and turn opening. Acoustic and thermal insulation complete the potential of this wooden window.A window that is available in different essences such as fir, larch, red grandis, oak and teak.
MATERIAL
Wood / Green / Environmentally Friendly
TYPE
Spruce, Larch, Okoumè, Oak, Teak
ENERGY LABEL
The energy index is based on English window standards. The actual energy consumption for a specific installation depends on the building and climatic conditions.
SAFETY
High
LIGHT TRANSMISSION
72 %
AIR PERMEABILITY CLASS (1-4)
CLASS 4
THERMAL INSULATION
0.84 W/m²K
SOUND INSULATION OF THE GLASS
Up to 45 dB
SOLAR FACTOR
49%
MAINTENANCE
Low
TYPE
- F window
- PF French door
- FX fixed
- RSA coplanar sliding
- BO horizontal pivot hinge
DETAIL
GLASS
Standard double glazing 33.1 low emissivity / 16/4/16 / 33.1 low emissivity with argon gas and thermal break spacer channel (Ug = 0.6 W / m2K). The glasses are sealed externally.
FINISHING
Varnishing with water cycle with natural or coloured anti-mold and anti-woodworm impregnating agent, base and finish.RC1 burglar-proof hardware configuration with mushroom-shaped locking points. The paints used have a low environmental impact.
CONSTRUCTION
Corner connection with cylindrical pins and anti-torsion joint, drain in the lower crosspiece of the frame. Frame section 79x80 mm. Leaf section 86x92 mm.
HARDWARE AND ACCESSORIES
Standard tilt-and-turn locking hardware with visible hinges and covers, capacity of 150 Kg, opening at 180 degrees. RC1 burglar-proof hardware configuration with mushroom-shaped locking points. Internal flat wire cover 65x10 mm and external 40x10 mm. Three thermo-acoustic seals..
