Leeboy 8515e Asphalt Pavers
8515E ASPHALT PAVERS
8515E ASPHALT PAVERS
Sleek, modern and low-profile are three words that immediately come to mind when evaluating the LeeBoy 8515E Asphalt Paver.
Featuring an engine hood height of 69 inches (1.75 m) and a sliding control station, the 8515E gives the operator an extremely clear and comfortable view of their surroundings.
With a class-leading tunnel size and self-cleaning conveyor bars, this machine is built to perform at the highest level. Easy-to-access, convenient maintenance areas are also a highlight of machine ownership.
INFORMATION
BRAND
Leeboy
PRODUCTION
Made in USA
PRODUCT TYPE
Asphalt Pavers
DIMENSIONS
- Length : 13’ 5”
- Height : 8’
- Width : 8’ 6” transport
10’ hopper wings down
COLLECTION
8515e
FUEL CAPACITIES
23.5 gallons
HYDRAULIC CAPACITIES
19 gallons
WASHDOWN TANK CAPACITIES
7 gallons
ENGINE
-Kubota turbocharged diesel -Tier 4 Final – 74 HP (55.4 kW) @ 2,200 rpm
TOTAL WEIGHT (WITH SCREED)
17.600 lbs
PAVING WIDTHS
Machine has variable paving widths up to 15’
OPERATOR’S CONTROLS
-Includes dual electronic steer -High deck/low deck configuration -Dash panel is movable from left to right and includes augers, screed extension, cut-offs, screed, hopper wings, conveyors, grade controls, steering and lights -Color graphic control screen with digital readouts. Review and monitor system vitals including: oil pressure, hour meter, fuel gauge, voltmeter, water temp, tachometer, hydraulic oil temp, engine diagnostics
